BLOCK ENGINE 7000379 (1)

BLOCK ENGINE 7000379 (1)

BLOCK ENGINE 7000379 (1)

1 7000379

  • 7000379 - BLOCK ENGINE
  • W/Ref. 2-13

2 6599985

  • 6599985 - LINER

3 6670337

  • 6670337 - PLUG

4 6652573

  • 6652573 - PLUG

5 6670338

  • 6670338 - PLUG

6 6657431

  • 6657431 - CAP

7 6652575

  • 6652575 - PLUG

8 6598116

  • 6598116 - PLUG

9 6652574

  • 6652574 - PLUG

10 6657423

  • 6657423 - PIN

11 21JM814

  • 21JM814 - PIN
  • dowel

12 3974039

  • 3974039 - PIN

13 3974037

  • 3974037 - PIN

14 6670339

  • 6670339 - PLUG

15 3974038

  • 3974038 - O-RING

16 6670344

  • 6670344 - PIN

17 6631010

  • 6631010 - SWITCH
  • PRESS OIL ENG
  • Oil Pressure

18 6670343

  • 6670343 - NUT

19 7022680

  • 7022680 - FITTING
  • DRAIN
  • Was 6657456

20 6670340

  • 6670340 - OIL PUMP

21 6670341

  • 6670341 - GASKET

22 6683010

  • 6683010 - BOLT

23 15JM48

  • 15JM48 - KEY

24 7247365

  • 7247365 - GEAR
  • OIL PUMP DRIVE
  • Was 6670342

25 6687663

  • 6687663 - PLUG
