FRAME 6914658

FRAME 6914658

FRAME 6914658

1 6914658

  • 6914658 - FRAME

2 7213359

  • 7213359 - BEARING SWING ID70L80

3 01775-6

  • 01775-6 - GREASE NIPPLE

4 96541-8

  • 96541-8 - RIVET

5 92708-7

  • 92708-7 - PLATE

6 1CM1025

  • 1CM1025 - BOLT

7 7252655

  • 7252655 - NUT LOCK

8 7229363

  • 7229363 - GASKET
  • BULK

9 6914715

  • 6914715 - STOP 90 MM

10 005329-79A

  • 005329-79A - SCREW

11 6914693

  • 6914693 - ARM ABUTMENT

12 14039-2

  • 14039-2 - SCREW

13 96336-3

  • 96336-3 - STOP

14 7215741

  • 7215741 - CHAIN

15 7168942

  • 7168942 - RING

16 7252655

  • 7252655 - NUT LOCK

17 6916450

  • 6916450 - RIVET

18 6922688

  • 6922688 - REAR COVER

19 01598-2

  • 01598-2 - SCREW

20 000350-02V

  • 000350-02V - WASHER

21 01681-6

  • 01681-6 - NUT

22 6922689

  • 6922689 - REAR COVER

23 4CM820

  • 4CM820 - SCREW HEX HD 8.8

24 000350-20Q

  • 000350-20Q - WASHER

25 6915265

  • 6915265 - SUPPORT LIGHT LH

26 6915264

  • 6915264 - SUPPORT LIGHT RH

27 100432-51C

  • 100432-51C - MIRROR
  • SIDE REAR

28 95218-4

  • 95218-4 - PIN

29 7215740

  • 7215740 - PIN
  • LOCK

30 96342-1

  • 96342-1 - BRACKET

31 01598-2

  • 01598-2 - SCREW

32 000350-02V

  • 000350-02V - WASHER

33 01681-6

  • 01681-6 - NUT

34 1CM1035

  • 1CM1035 - BOLT

35 1EM100

  • 1EM100 - WASHER PLAIN

36 7197860

  • 7197860 - REFLECTOR
