VALVE, CONTROL 5050656088

VALVE, CONTROL 5050656088

VALVE, CONTROL 5050656088

1 5050656088

  • 5050656088 - VALVE
  • CONTROL

2 5003700003

  • 5003700003 - CONNECTING PLATE

3 1045907011

  • 1045907011 - BOLT
  • M 5X45

4 1045707513

  • 1045707513 - BOLT
  • M 6X25

5 1290707014

  • 1290707014 - WASHER
  • 6
  • 4

6 1212251009

  • 1212251009 - NUT
  • M 6

7 1915060255

  • 1915060255 - FITTING

8 4506152351

  • 4506152351 - HOSE
  • ASSEMBLY CPL.

9 1924060151

  • 1924060151 - FITTING

10 4506097351

  • 4506097351 - HOSE

11 1919060351

  • 1919060351 - FITTING

12 5000210400

  • 5000210400 - HOSE CLIP

13 1008707719

  • 1008707719 - BOLT
  • M 8X60

14 1290707018

  • 1290707018 - WASHER
  • 8
  • 4

15 1212251011

  • 1212251011 - NUT
  • M 8

16 4506072351

  • 4506072351 - HOSE

17 1915000905

  • 1915000905 - FITTING

18 1921060154

  • 1921060154 - FITTING

19 1212251013

  • 1212251013 - NUT
  • M 10

20 0451539005

  • 0451539005 - VALVE
  • PLATE

21 1008707924

  • 1008707924 - BOLT
  • M 10X65

22 0188814218

  • 0188814218 - SLEEVE
  • DISTANCE

23 1290707020

  • 1290707020 - WASHER
  • 10
  • 5
