UPPERSTRUCTURE 6217105002

UPPERSTRUCTURE 6217105002

UPPERSTRUCTURE 6217105002

1 6217105002

  • 6217105002 - UPPERSTRUCTURE

2 0176105230

  • 0176105230 - PIN
  • BOOM CYL

3 0156029033

  • 0156029033 - SPACER

4 1343707061

  • 1343707061 - WASHER

5 1008707829

  • 1008707829 - BOLT

6 5809625664

  • 5809625664 - BUSHING

7 1607010006

  • 1607010006 - NIPPLE
  • GREASE

8 6207506060

  • 6207506060 - BRACKET
  • BATTERY

9 1008707018

  • 1008707018 - BOLT

10 1343707057

  • 1343707057 - WASHER

11 0209006046

  • 0209006046 - WASHER

12 6209006047

  • 6209006047 - WASHER

13 0190006009

  • 0190006009 - HOSE

14 1915060583

  • 1915060583 - FITTING

15 1915060551

  • 1915060551 - FITTING

16 1007707356

  • 1007707356 - BOLT
  • M20X260

17 1343707069

  • 1343707069 - WASHER

18 1212251011

  • 1212251011 - NUT

19 6207506030

  • 6207506030 - SHEET-METAL

20 1307707018

  • 1307707018 - WASHER

21 6207506034

  • 6207506034 - SHEET-METAL

22 6190006036

  • 6190006036 - PLATE

23 6207506031

  • 6207506031 - BRACKET

24 1008707318

  • 1008707318 - BOLT

25 0207528050

  • 0207528050 - FRAME

26 1008707030

  • 1008707030 - BOLT

27 1343707059

  • 1343707059 - WASHER

28 6207528030

  • 6207528030 - COVER

29 5558652025

  • 5558652025 - PLUG
  • PROTECTION

30 6207528031

  • 6207528031 - COVER

31 0207506010

  • 0207506010 - COUNTERWEIGHT

32 5354576810

  • 5354576810 - HANDLE

33 1046707213

  • 1046707213 - BOLT
  • M6X20

34 1980930193

  • 1980930193 - PLUG
  • PROTECTION

35 1007707153

  • 1007707153 - BOLT
  • M20X70

36 0207506061

  • 0207506061 - STUD

37 1245707011

  • 1245707011 - WING NUT

38 1607003010

  • 1607003010 - GREASE NIPPLE
