(SK200SR) - SHORT RADIUS EXCAVATOR BTW YB04-02301 - YB04-02550 (1/03-12/04)
/
FUEL LINES YB21P00003F2 (2)

FUEL LINES YB21P00003F2 (2)

FUEL LINES YB21P00003F2 (2)

1 YB21P00003F2

  • YB21P00003F2 - FUEL LINES

2 2444R2492D240

  • 2444R2492D240 - HOSE

3 2418Z1333D22

  • 2418Z1333D22 - PROTECTIVE SLEEVE
  • 19.5mm ID x 23.8mm OD x 2250mm Length

4 ZC16X01800

  • ZC16X01800 - CLIP

5 PY01P01043D2

  • PY01P01043D2 - CABLE TIE
  • 4.60mm W x 202mm L

6 YB21P01001P1

  • YB21P01001P1 - GROMMET

7 YT13E01018P2

  • YT13E01018P2 - GROMMET

8 ZS18C08025

  • ZS18C08025 - SCREW
  • Hex
  • M8 x 25mm

9 ZW16X08000

  • ZW16X08000 - WASHER
  • 8mm ID x 17mm OD x 1.6mm Thk

10 2444R2492D100

  • 2444R2492D100 - FLEXIBLE HOSE

11 2444R2492D235

  • 2444R2492D235 - FLEXIBLE HOSE

12 2418Z1333D2

  • 2418Z1333D2 - PROTECTIVE SLEEVE
  • 19.5mm ID x 23.8mm OD x 900mm Length

13 HX11Y06038DX

  • HX11Y06038DX - FLEXIBLE HOSE

14 YF02P01001F2

  • YF02P01001F2 - SEPARATOR
