(SK200SR) - SHORT RADIUS EXCAVATOR BTW YB04-02301 - YB04-02550 (1/03-12/04)
/
HARNESS ASSY, UPP YB13E00007F2 (2)

HARNESS ASSY, UPP YB13E00007F2 (2)

HARNESS ASSY, UPP YB13E00007F2 (2)

1 YB13E00007F2

  • YB13E00007F2 - HARNESS ASSY
  • UPP

2 LE13E01005P1

  • LE13E01005P1 - CABLE
  • 100mm L

3 ZS18C08016

  • ZS18C08016 - SCREW
  • Hex
  • M8 x 16mm

4 ZW26X08000

  • ZW26X08000 - LOCK WASHER

5 ZW16X08000

  • ZW16X08000 - WASHER
  • 8mm ID x 17mm OD x 1.6mm Thk

6 PY01P01043D3

  • PY01P01043D3 - CABLE TIE
  • 188mm L

7 YB13E01024P1

  • YB13E01024P1 - HARNESS
