SUPPORT 87434992
1 87434992
- 87434992 - SUPPORT
2 87427004
- 87427004 - SUPPORT
3 87426960
- 87426960 - PIVOT ASSY.
4 87453116
- 87453116 - SUPPORT
5 87453117
- 87453117 - SUPPORT
6 15213721
- 15213721 - BOLT
- Hex
- M8 x 60mm
- Cl 8.8
- Full Thd
7 16100811
- 16100811 - NUT
- Hex
- M8
- 6.80mm
- Cl 8
- ZND
8 47048969
- 47048969 - WASHER
- 11mm ID x 24mm OD x 2mm Thk
9 47048992
- 47048992 - LOCK WASHER
- 8mm ID
10 47049041
- 47049041 - NUT
- Hex
- M10 x 1.5
- Cl 8
11 47049082
- 47049082 - BOLT
- Hex
- M8 x 1.25 x 35mm
- Cl 8.8
12 87453118
- 87453118 - LEVER
13 84058418
- 84058418 - BOLT
- Hex
- M10 x 125mm
- Cl 8.8
14 85824053
- 85824053 - CIRCLIP
- #100
- .925"
- Ext
15 85824054
- 85824054 - WASHER
16 85824059
- 85824059 - BUSHING
- 19.15mm ID x 23.83mm OD x 10.6mm L
17 87453110
- 87453110 - SPACER
- 12mm ID x 17mm OD x 91mm L
18 87405706
- 87405706 - WAVE WASHER
- 27mm ID x 34mm OD x 2.52mm Thk
19 47049032
- 47049032 - NUT
- Hex
- M12
- Cl 10
20 47049151
- 47049151 - SCREW
- M12 x 40mm
- Cl 8.8
