New Holland Construction
/
(B95B) - LOADER BACKHOE - TIER 3 NRC (7/12-)
/
BOLT,Hex, M16 x 2 x 120mm, Cl 8.8 321246 (1)

BOLT,Hex, M16 x 2 x 120mm, Cl 8.8 321246 (1)

BOLT,Hex, M16 x 2 x 120mm, Cl 8.8 321246 (1)

1 321246

  • 321246 - BOLT
  • Hex
  • M16 x 2 x 120mm
  • Cl 8.8

2 87630175

  • 87630175 - WASHER
  • 0.66" ID x 3" OD x 0.18" Thk

3 84383344

  • 84383344 - ISOLATOR
  • 80mm OD x 40.5mm L

4 84468544

  • 84468544 - BRACKET

5 87655043

  • 87655043 - WASHER
  • M12
  • 13.65mm ID x 24.90mm OD x 3.20mm
  • HT Boron
  • ZNM

6 300389

  • 300389 - BOLT
  • M12 x 1.75 x 35mm
  • Cl 8.8

7 86592702

  • 86592702 - WASHER
  • 17mm ID x 45mm OD x 6mm Thk

8 412066

  • 412066 - NUT
  • M16 x 2.0
  • Cl 8

9 84468545

  • 84468545 - BRACKET
