VALVE LF30V00002F1 (3)
1 LF30V00002F1
- LF30V00002F1 - VALVE
- CONTROL
- Incl. 1 - 4
2 NSS
- NSS - NOT SERVICED SEPARATELY
- VALVE ASSY
- CONTROL (MAIN)
3 YT30V00018F1
- YT30V00018F1 - CONTROL VALVE
- Incl. 2-1 - 24
- See Figure 207
- 208
4 YT22V00004F1
- YT22V00004F1 - VALVE
- OVERLOAD RELIEF See Figure 203
5 YN01V00004S006
- YN01V00004S006 - O-RING
6 ZD12P02200
- ZD12P02200 - O-RING
7 ZD12P01600
- ZD12P01600 - O-RING
- O-RING
8 YT30V00001S005
- YT30V00001S005 - COVER
- Incl. 3-1
- 3-2
9 YN01V00004S006
- YN01V00004S006 - O-RING
10 ZD12P02200
- ZD12P02200 - O-RING
11 ZS23C12065
- ZS23C12065 - SCREW
- Hex Socket Head
- M12 x 65mm
