Гусек 12199645
1 12199690
- 12199690 - [A] Welding body of the upper section arm of the auxiliary arm
- Кол-во: 1
2 11419426
- 11419426 - Pedal fixed chain
- Кол-во: 11
3 11104148
- 11104148 - Fixed seat
- Кол-во: 22
4 A210211000023
- A210211000023 - screw
- Кол-во: 22
5 11098983
- 11098983 - Pedal (370x2900)
- Кол-во: 1
6 A210111000091
- A210111000091 - bolt
- Кол-во: 8
7 A210405000007
- A210405000007 - washer
- Кол-во: 20
8 A210314000008
- A210314000008 - nut
- Кол-во: 12
9 11104149
- 11104149 - Connecting board
- Кол-во: 2
10 11503919
- 11503919 - Wear-resistant plate
- Кол-во: 2
11 A210204000164
- A210204000164 - Screw M8x30GB70.1
- Кол-во: 4
12 11141477
- 11141477 - Pedal 370x830
- Кол-во: 1
13 12163440
- 12163440 - Pull plate
- Кол-во: 2
14 12199701
- 12199701 - [A] Force limiter assembly
- Кол-во: 2
15 12199696
- 12199696 - Pull plate
- Кол-во: 2
16 21038959
- 21038959 - Copper sleeve
- Кол-во: 4
17 21040083
- 21040083 - Pulley assembly
- Кол-во: 6
18 12199639
- 12199639 - Spacer
- Кол-во: 1
19 21038688
- 21038688 - board
- Кол-во: 2
20 12199640
- 12199640 - Spacer
- Кол-во: 1
21 12199644
- 12199644 - Spacer
- Кол-во: 3
22 21012137
- 21012137 - Pin pin
- Кол-во: 8
23 12199641
- 12199641 - Retaining rope tube
- Кол-во: 3
24 10456217
- 10456217 - Wiring harness holder
- Кол-во: 32
25 A210401000016
- A210401000016 - washer
- Кол-во: 32
26 A210111000080
- A210111000080 - bolt
- Кол-во: 32
27 12199643
- 12199643 - axis
- Кол-во: 1
28 21038512
- 21038512 - pulley
- Кол-во: 4
29 12199642
- 12199642 - tube
- Кол-во: 2
30 12199638
- 12199638 - [T] Pulley shaft
- Кол-во: 1
31 12199636
- 12199636 - [T] Axle
- Кол-во: 2
32 A210401000004
- A210401000004 - Washer 16GB93
- Кол-во: 24
33 A210204000165
- A210204000165 - Screw M16x40GB70.1
- Кол-во: 24
34 A210111000204
- A210111000204 - bolt
- Кол-во: 4
35 21001334
- 21001334 - Washer 12GB97.1 300HV
- Кол-во: 4
36 12199637
- 12199637 - board
- Кол-во: 2
37 12199635
- 12199635 - [T] Pulley shaft
- Кол-во: 1
38 21012138
- 21012138 - Pin pin
- Кол-во: 4
39 12134504
- 12134504 - Luffing auxiliary arm upper section arm electrical
- Кол-во: 1
