Система электрическая поворотной платформы (часть 2) 13936804
16 12599404
- 12599404 - Platform camera and lighting installation
- Кол-во: 1
17 60224110
- 60224110 - 10m video cable PL10HK (TS-MC10)
- Кол-во: 1
18 14067368
- 14067368 - Inclination sensor assembly
- Кол-во: 1
19 13936781
- 13936781 - Installation of junction box at the front of the turntable
- Кол-во: 1
20 11326017
- 11326017 - Adapter cable assembly
- Кол-во: 1
21 A810201206238
- A810201206238 - Pressure sensor 10MPa-24V-I-G1/4-M12
- Кол-во: 1
22 13562408
- 13562408 - Installation of rotary reset device
- Кол-во: 1
23 60118196
- 60118196 - Proximity switch NB10-30M60-A1-V1
- Кол-во: 2
24 A810201206126
- A810201206126 - Pressure sensor 60MPa-24V-I-G1/4-M12 Sany
- Кол-во: 5
25 13939087
- 13939087 - Installation of 5 distribution boxes on the right side of the turntable
- Кол-во: 1
26 12102247
- 12102247 - 4 installation of distribution box on the right side of the platform
- Кол-во: 1
27 12102242
- 12102242 - Installation of 3 distribution boxes on the right side of the platform
- Кол-во: 1
28 12102199
- 12102199 - Installation of the distribution box 2 on the right side of the platform
- Кол-во: 1
29 12102190
- 12102190 - Installation of distribution box 1 on the right side of the platform
- Кол-во: 1
30 A810201206239
- A810201206239 - Temperature transmitter SYTT-ZI(-30) 90lV-M121-G1/2
- Кол-во: 1
31 A210210000018
- A210210000018 - bolt
- Кол-во: 24
32 A210405000004
- A210405000004 - washer
- Кол-во: 24
33 A210401000013
- A210401000013 - washer
- Кол-во: 24
34 13936789
- 13936789 - Installation of 3 distribution boxes on the left side of the turntable
- Кол-во: 1
35 13936787
- 13936787 - Installation of the distribution box 2 on the left side of the turntable
- Кол-во: 1
36 13936784
- 13936784 - Installation of distribution box 1 on the left side of the turntable
- Кол-во: 1
37 60224109
- 60224109 - 5m video cable PL5HK (TS-MC5)
- Кол-во: 2
