Кронштейны двигателя и генератор
1 B00004172
- B00004172 - HEXAGON HEAD BOLTS
- Кол-во: 4
- GB/T5783-M20*45-10.9
2 B00001246
- B00001246 - SINGLE COIL SPRING LOCK WASHERS
- NORMAL TYPE
- Кол-во: 4
- GB/T93-20
3 W04D00101
- W04D00101 - EYE PLATE ASSY (WELDED)
- Кол-во: 1
4 B00004173
- B00004173 - HEXAGON HEAD BOLTS
- Кол-во: 4
- GB/T5785-M12*1.5*110-10.9
5 B00001239
- B00001239 - SINGLE COIL SPRING LOCK WASHERS
- NORMAL TYPE
- Кол-во: 11
- GB/T93-12
6 B00004192
- B00004192 - WASHER WITH BALL FACE
- Кол-во: 4
- GB/T849-12
7 B00002056
- B00002056 - HEXAGON BOLTS WITH FLANGE
- Кол-во: 2
- Q/SC622-M12*35-ZN.D
8 W02F10301
- W02F10301 - BRACKET
- FUEL INJECTION PUMP
- Кол-во: 1
9 W02F10201
- W02F10201 - BOLTS
- FUEL INJECTION PUMP BRACKET
- Кол-во: 3
10 S00003634
- S00003634 - SPACER
- Кол-во: 2
11 W04D10301
- W04D10301 - HOISTING HANGING
- Кол-во: 2
12 B00002065
- B00002065 - HEXAGON BOLTS WITH FLANGE
- Кол-во: 2
- Q/SC622-M12*50-ZN.D
13 B00002050
- B00002050 - HEXAGON BOLTS WITH FLANGE
- Кол-во: 19
- Q/SC622-M12*30
14 W02F11403
- W02F11403 - ALTERNATOR BRACKET
- Кол-во: 1
15 B00002009
- B00002009 - HEXAGON BOLTS WITH FLANGE
- Кол-во: 2
- Q/SC622-M10*40-ZN.D
16 B00002003
- B00002003 - HEXAGON BOLTS WITH FLANGE
- Кол-во: 3
- Q/SC622-M10*30-ZN.D
17 W02F11501
- W02F11501 - BOLT
- Кол-во: 1
18 B00002000
- B00002000 - HEXAGON BOLTS WITH FLANGE
- Кол-во: 42
- Q/SC622-M10*25-ZN.D
19 B00000772
- B00000772 - HEXAGON NUTS
- STYLE 1
- Кол-во: 2
- GB/T6170-M12-Y
20 G1110701
- G1110701 - ROD SLEEVE
- Кол-во: 1
21 B00002139
- B00002139 - HEXAGON BOLTS WITH FLANGE
- Кол-во: 1
- Q/SC622-M8*30
22 B00004833
- B00004833 - HEXAGON BOLTS WITH FLANGE
- Кол-во: 1
- GB/T16674.1-M10*140
23 W11B00002
- W11B00002 - ALTERNATOR
- Кол-во: 1
24 W02F10403
- W02F10403 - ALTERNATOR BRACKET
- Кол-во: 1
25 B00000834
- B00000834 - HEXAGON NUTS WITH FLANGE-FINE PITCH THREAD
- Кол-во: 1
- GB/T6177-M10-Zn.D
26 W33A10101
- W33A10101 - ENGINE SUPPORT
- FRONT
- Кол-во: 2
27 B00001284
- B00001284 - PLAIN WASHER
- Кол-во: 8
- GB/T97.1-16-200HV-Y
28 B00001243
- B00001243 - SINGLE COIL SPRING LOCK WASHERS
- NORMAL TYPE
- Кол-во: 12
- GB/T93-16
29 B00004171
- B00004171 - HEXAGON HEAD BOLTS
- Кол-во: 8
- GB/T5783-M16*50-10.9
30 B00002196
- B00002196 - WASHER
- Кол-во: 2
- Q/SC642.1-03-18
31 W02F00101
- W02F00101 - WATER DRAIN PIPE ASSY
- Кол-во: 1
32 B00002181
- B00002181 - HINGE BOLT
- Кол-во: 1
- Q/SC642.1-01-M18*1.5
33 W02F11101
- W02F11101 - GASKET
- SIDE COVER PLATE
- CYLINDER BLOCK
- Кол-во: 5
34 W02F11701
- W02F11701 - COVER
- CYLINDER BLOCK
- Кол-во: 1
35 B00004892
- B00004892 - HEXAGON BOLTS WITH FLANGE
- Кол-во: 4
- GB/T16674.1-M6*16-10.9-F
36 W02F10801
- W02F10801 - SIDE COVER PLATE WELDING ASSY
- CYLINDER BLOCK
- Кол-во: 4
37 B00000572
- B00000572 - HEXAGON HEAD BOLTS
- Кол-во: 4
- GB/T5783-M16*40
38 W02F10101
- W02F10101 - PLATE
- INTERCOOLER
- Кол-во: 1
39 B00000541
- B00000541 - HEXAGON HEAD BOLTS
- Кол-во: 4
- GB/T5783-M12*30
40 W02F10901
- W02F10901 - GASKET
- CAMSHAFT PLATE
- Кол-во: 5
41 W02F11201
- W02F11201 - BRACKET
- RAW/FLESH WATER HEAT EXCHANGE
- Кол-во: 2
42 W02F11301
- W02F11301 - BRACKET COVER
- RAW/FLESH WATER HEAT EXCHANGE
- Кол-во: 2
43 B00002072
- B00002072 - HEXAGON BOLTS WITH FLANGE
- Кол-во: 4
- Q/SC622-M12*65
44 W02F10601
- W02F10601 - PLATE
- CAMSHAFT
- Кол-во: 3
45 B00002049
- B00002049 - HEXAGON BOLTS WITH FLANGE
- Кол-во: 24
- Q/SC622-M12*25-ZN.D
