Система впуска воздуха C12AZ-12AZ302
1 C12AL12AL602
- C12AL12AL602 - HOSE-AIR
- Кол-во: 1
2 B00001539
- B00001539 - SPRING CLAMP
- Кол-во: 2
- Q/SC1092-70
3 C12AL12AL601
- C12AL12AL601 - ELBOW-AIR TRANSFER
- Кол-во: 1
4 B00002007
- B00002007 - HEXAGON BOLTS WITH FLANGE-SMALL SERIES
- Кол-во: 4
- Q/SC622-M10*40
5 B00002001
- B00002001 - HEXAGON BOLTS WITH FLANGE-SMALL SERIES
- Кол-во: 4
- Q/SC622-M10*30
6 C12ALM1H7666
- C12ALM1H7666 - GASKET
- Кол-во: 1
7 C12AL12AL604
- C12AL12AL604 - AIR INLET PIPE ELBOW
- CYLINDER HEAD
- Кол-во: 1
8 B00001724
- B00001724 - HEXAGONAL HEAD SCREW PLUG
- Кол-во: 1
- Q/SC587.1-M10*1
9 B00001814
- B00001814 - COPPER WASHERS
- Кол-во: 1
- Q/SC598-10*16
10 U562AM5M6214
- U562AM5M6214 - PLUG PIPE
- Кол-во: 1
11 C12AL12AL605
- C12AL12AL605 - GASKET
- Кол-во: 1
12 B00001729
- B00001729 - HEXAGONAL HEAD SCREW PLUG
- Кол-во: 1
- Q/SC587.1-M20*1.5
13 B00001550
- B00001550 - COMPOSITED HARD SEAL WASHERS
- Кол-во: 1
- Q/SC1294-20
14 C12ALM8N8196
- C12ALM8N8196 - ADAPTER
- EXHAUST MANIFOLD
- Кол-во: 1
15 C12ALM1S4295
- C12ALM1S4295 - GASKET
- INLET TURBINE
- Кол-во: 1
16 C38ALM7L3195
- C38ALM7L3195 - BOLT-HIGH TEMP
- Кол-во: 4
17 C13BLM2N2766
- C13BLM2N2766 - LOCK NUT
- Кол-во: 4
