Трубопровод масляный турбонагнетателя C19BZ-19BZ606
1 C19BB19BB626
- C19BB19BB626 - TUBE AS
- Кол-во: 1
2 C19BB19BB602
- C19BB19BB602 - TUBE AS.
- Кол-во: 1
3 C19BL19BL627
- C19BL19BL627 - BRACKET
- FUEL INJECTION PUMP
- Кол-во: 1
3 C19BL19BL626
- C19BL19BL626 - SUPPORT
- FUEL INJECTION PUMP
- Кол-во: 1
3 B00002061
- B00002061 - HEXAGON BOLTS WITH FLANGE-SMALL SERIES
- Кол-во: 2
- Q/SC622-M12*45-10.9
6 C19BB19BB622
- C19BB19BB622 - FUEL INLET TUBE
- FUEL INJECTION PUMP
- Кол-во: 1
8 C19BLM19BL205
- C19BLM19BL205 - TIE-IN
- Кол-во: 1
10 B00000635
- B00000635 - BOLT
- Кол-во: 3
- GB/T5783-M8*25-10.9
11 C19BLM8N1149
- C19BLM8N1149 - ELBOW
- Кол-во: 1
12 U641A9M4849
- U641A9M4849 - SEAL-O-RING
- Кол-во: 1
13 U641A8M5248
- U641A8M5248 - SEAL-O-RING
- Кол-во: 2
14 U641A8M5253
- U641A8M5253 - SEAL-O-RING
- Кол-во: 1
15 U641A3K0360
- U641A3K0360 - SEAL-O-RING
- Кол-во: 2
16 C19BL6N6033
- C19BL6N6033 - CLIP
- Кол-во: 2
17 U511BM8M0505
- U511BM8M0505 - CONNECTOR
- Кол-во: 1
18 B00002177
- B00002177 - PLUG-PIPE
- Кол-во: 1
- Q/SC642.1-01-M10*1
19 C02BL4M6480
- C02BL4M6480 - GASKET
- Кол-во: 1
20 C19BL8H9788
- C19BL8H9788 - GASKET
- Кол-во: 1
21 C19BL19BL020
- C19BL19BL020 - GASKET
- Кол-во: 1
22 B00000638
- B00000638 - BOLT
- Кол-во: 2
- GB/T5783-M8*30-10.9
23 B00001299
- B00001299 - WASHER
- Кол-во: 6
- GB/T97.1-8-200HV-Y
24 B00001275
- B00001275 - WASHER
- Кол-во: 2
- GB/T97.1-10-200HV-Y
25 B00000456
- B00000456 - BOLT
- Кол-во: 1
- GB/T5782-M16*100-10.9
26 B00000792
- B00000792 - NUT
- Кол-во: 1
- GB/T6170-M8-10-Y
27 B00001284
- B00001284 - WASHER
- Кол-во: 1
- GB/T97.1-16-200HV-Y
28 B00002167
- B00002167 - BOLT
- Кол-во: 2
- Q/SC622-M8*90-10.9
29 B00000402
- B00000402 - BOLT
- Кол-во: 1
- GB/T5782-M10*60-10.9
30 B00001545
- B00001545 - WASHER
- Кол-во: 2
- Q/SC1294-10
31 B00000510
- B00000510 - BOLT
- Кол-во: 3
- GB/T5783-M10*30-10.9
