Система топливная G26-000-07+E
1 G2600107A
- G2600107A - HIGH PRESSURE FUEL TUBE ASSY (NO.1 CYLINDER)
- Кол-во: 1
2 G2600207A
- G2600207A - HIGH PRESSURE FUEL TUBE ASSY (NO.2 CYLINDER)
- Кол-во: 1
3 G2600307A
- G2600307A - HIGH PRESSURE FUEL TUBE ASSY (NO.3 CYLINDER)
- Кол-во: 1
4 G2600407A
- G2600407A - HIGH PRESSURE FUEL TUBE ASSY (NO.4 CYLINDER)
- Кол-во: 1
5 G2600507A
- G2600507A - HIGH PRESSURE FUEL TUBE ASSY (NO.5 CYLINDER)
- Кол-во: 1
6 761G26063B
- 761G26063B - FUEL RETURN PIPE
- Кол-во: 1
7 B00002232
- B00002232 - BANJO BOLT
- Кол-во: 6
- Q/SC642.3-1-M8*1*22
8 B00001555
- B00001555 - RUBBER COATED HARD WASHER
- Кол-во: 12
- Q/SC1294-8
9 B00002118
- B00002118 - HEX HEAD BOLT
- Кол-во: 12
- Q/SC622-M6*20
10 A762ZA26004A
- A762ZA26004A - CLAMP
- Кол-во: 6
11 A762ZA26003A
- A762ZA26003A - CLAMP CUSHION
- Кол-во: 12
12 A762ZA26010A
- A762ZA26010A - BRACKET ASSY (WELDED)
- VITTA
- Кол-во: 6
13 G2600607A
- G2600607A - HIGH PRESSURE FUEL TUBE ASSY (NO.6 CYLINDER)
- Кол-во: 1
14 G2611501A
- G2611501A - CLAMP
- Кол-во: 1
15 G2611701A
- G2611701A - CLAMP
- Кол-во: 11
16 B00002104
- B00002104 - HEX HEAD BOLT
- Кол-во: 8
- Q/SC622-M5*16
17 B00000839
- B00000839 - HEXAGON NUTS WITH FLANGE-FINE PITCH THREAD
- Кол-во: 8
- GB/T6177-M5-8-Y
18 B00002132
- B00002132 - HEX HEAD BOLT
- Кол-во: 1
- Q/SC622-M8*16
19 77126014A
- 77126014A - LOW PRESSURE FUEL TUBE
- Кол-во: 1
20 77126180A
- 77126180A - OIL RETURN PIPE ASSY (WELDED)
- Кол-во: 1
21 763G26001AA
- 763G26001AA - HOSE
- Кол-во: 1
22 G2610401A
- G2610401A - CLAMP
- Кол-во: 1
23 B00001999
- B00001999 - HEX HEAD BOLT
- Кол-во: 1
- Q/SC622-M10*25
24 G2611401A
- G2611401A - CLAMP
- Кол-во: 1
25 77126015A
- 77126015A - LOW PRESSURE FUEL TUBE
- Кол-во: 1
26 G2600701A
- G2600701A - CLAMP ASSY (WELDED)
- Кол-во: 2
27 G2611601A
- G2611601A - CLAMP
- Кол-во: 2
28 B00001104
- B00001104 - STUD
- Кол-во: 8
- GB/T899-GM10-M10*35-8.8-Y
29 765KB02002A
- 765KB02002A - SPACER
- Кол-во: 2
