Система впуска воздуха S00008465+04
1 S0000846401
- S0000846401 - AIR INTAKE SYSTEM
- Кол-во: 1
2 G1210601B
- G1210601B - INTERCOOLER GASKET
- Кол-во: 1
3 B00000846
- B00000846 - HEXAGON NUTS WITH FLANGE-FINE PITCH THREAD
- Кол-во: 6
- GB/T6177-M8-Y
4 B00001159
- B00001159 - STUD
- Кол-во: 6
- GB/T899-M8*20-8.8-Y
5 B00001253
- B00001253 - SPRING WASHER
- Кол-во: 22
- GB/T93-8
6 B00000917
- B00000917 - HEXAGON SOCKET HEAD CAP SCREW
- Кол-во: 22
- GB/T70-M8*25
7 G1210801A
- G1210801A - GASKET
- Кол-во: 1
8 B00002001
- B00002001 - HEX HEAD BOLT
- Кол-во: 4
- Q/SC622-M10*30
9 G1200204B
- G1200204B - AIR INTAKE PIPE ASSY
- Кол-во: 1
10 B00001543
- B00001543 - SPRING CLAMP
- Кол-во: 2
- Q/SC1092-90
11 B00001629
- B00001629 - HOSE
- Кол-во: 1
- Q/SC1372-80*80
12 B00001996
- B00001996 - HEX HEAD BOLT
- Кол-во: 2
- Q/SC622-M10*20
13 B00002132
- B00002132 - HEX HEAD BOLT
- Кол-во: 2
- Q/SC622-M8*16
14 D02A16701C
- D02A16701C - ELBOW CONNECTOR
- Кол-во: 1
15 D2613201A
- D2613201A - FUEL INJECTION PUMP OIL INLET TUBE ASSY
- Кол-во: 1
16 B00002465
- B00002465 - HOSE
- Кол-во: 1
- Q/SC646-89*80
17 B00001586
- B00001586 - CLAMP
- Кол-во: 2
- Q/SC1302-91~114
18 G1200304A
- G1200304A - AIR FILTER BRACKET ASSY (WELDED)
- Кол-во: 1
19 G1200402A
- G1200402A - CAP ADAPTER ASSY (WELDED)
- Кол-во: 1
