Bobcat
/
316.0
/
SEAT BELT 6817076 (2)

SEAT BELT 6817076 (2)

SEAT BELT 6817076 (2)

1 6817076

  • 6817076 - SEAT BELT

2 NTS2-60001

  • NTS2-60001 - PLATE

3 0311-08000-A

  • 0311-08000-A - NUT

4 NTS2-60051

  • NTS2-60051 - INSULATION

5 NTS2-60052-1

  • NTS2-60052-1 - INSULATION

6 NTS2-60053-1

  • NTS2-60053-1 - INSULATION

7 NTS2-60055

  • NTS2-60055 - INSULATION

8 0813-07300-0

  • 0813-07300-0 - RUBBER
  • TRIM
  • Was 0813-07300-O

9 NTS2-60036-1

  • NTS2-60036-1 - STAY

10 0389-08000-A

  • 0389-08000-A - WASHER

11 0421-08034-O

  • 0421-08034-O - PIN
  • SNAP
  • snap

12 0102-08030-A

  • 0102-08030-A - BOLT

13 0387-08000-A

  • 0387-08000-A - WASHER
  • 8
  • 5mm IDx24
  • 5mm ODx2
  • 3mm Thk - M8

14 NTS2-60400-B

  • NTS2-60400-B - COVER
  • engine - W/Ref. 30

15 121-3587

  • 121-3587 - HANDLE

16 NTS2-60028

  • NTS2-60028 - PLATE

17 41301-01630

  • 41301-01630 - CYLINDER
  • Use ignition key

18 41307-00007

  • 41307-00007 - IGNITION KEY

19 NTS2-60412-A

  • NTS2-60412-A - PLATE

20 NTS2-60413-0

  • NTS2-60413-0 - LOCK

21 NTS2-60411-0

  • NTS2-60411-0 - PLATE

22 0102-06025-A

  • 0102-06025-A - BOLT
  • M6x25

23 0389-06000-A

  • 0389-06000-A - WASHER

24 NTS2-61000-0

  • NTS2-61000-0 - TOOL BOX

25 0102-08020-A

  • 0102-08020-A - BOLT

26 0813-08108-0

  • 0813-08108-0 - TRIM
  • RUBBER
  • 1080C

27 0814-12000-A

  • 0814-12000-A - BUSHING
  • RUBBER
  • rubber

28 NTS2-61007-0

  • NTS2-61007-0 - CLIP
  • catch

29 0331-04010-A

  • 0331-04010-A - SCREW
  • M4x10

30 0251-08000-A

  • 0251-08000-A - NUT
  • M8
