A/C UPGRADE KIT

A/C UPGRADE KIT

A/C UPGRADE KIT

1 7103505

  • 7103505 - A/C UPGRADE KIT
  • For heater box W/top access filter

2 6624289

  • 6624289 - STRAP
  • TIE

3 6675838

  • 6675838 - BUSHING
  • ALTNTR BRKT

4 6676169

  • 6676169 - NUT

5 6676713

  • 6676713 - LOUVER

6 6680311

  • 6680311 - RECEIVER
  • DRIER A/C
  • W/O pressure switch - use switch 6675779

7 6681716

  • 6681716 - COMPRESSOR
  • A/C

8 6681878

  • 6681878 - LATCH

9 6682037

  • 6682037 - CONDENSER

10 6683909

  • 6683909 - COIL

11 6683910

  • 6683910 - VALVE

12 6683911

  • 6683911 - SWITCH
  • THERMOSTAT

13 6684418

  • 6684418 - IDLER

14 6684499

  • 6684499 - WASHER

15 6684500

  • 6684500 - WASHER

16 6685114

  • 6685114 - SCREW

17 6685115

  • 6685115 - WASHER

18 6685116

  • 6685116 - SCREW

19 6685117

  • 6685117 - O-RING

20 6685132

  • 6685132 - SHIELD
  • Was 6685133

21 6704444

  • 6704444 - WASHER

22 7169112

  • 7169112 - SWITCH
  • ROCKER A/C
  • Was 6719176

23 6732732

  • 6732732 - BUSHING

24 6807220

  • 6807220 - SPACER

25 6808436

  • 6808436 - GROMMET

26 6813975

  • 6813975 - PLATE

27 6814024

  • 6814024 - SCREW

28 6814859

  • 6814859 - TENSOINER

29 6814861

  • 6814861 - SPACER

30 7001433

  • 7001433 - CAP
  • END
  • charge port cap

31 6679085

  • 6679085 - SWITCH
  • LOW
  • LPCO

32 6816871

  • 6816871 - HOSE
  • W/ 6679085 switch

33 6817028

  • 6817028 - SPACER

34 6817088

  • 6817088 - HOSE

35 7001433

  • 7001433 - CAP
  • END
  • charge port cap

36 6817091

  • 6817091 - HOSE

37 6817093

  • 6817093 - BRACKET

38 6688529

  • 6688529 - HOSE
  • Was 6817726

39 6818176

  • 6818176 - SPACER

40 6818217

  • 6818217 - TENSIONER

41 7101068

  • 7101068 - BELT

42 6818326

  • 6818326 - BELT
  • Europe sound requirement

43 6818334

  • 6818334 - HARNESS
  • AC

44 6818366

  • 6818366 - SCREW

45 7103231

  • 7103231 - BRACKET

46 29CM816

  • 29CM816 - SCREW FLGD HEX CAP

47 1CM880

  • 1CM880 - SCREW HEX HD 8.8

48 1CM885

  • 1CM885 - BOLT

49 1CM8100

  • 1CM8100 - SCREW HEX CAP

50 1CM8110

  • 1CM8110 - SCREW HEX HD 8.8

51 5CM1025

  • 5CM1025 - SCREW FL THD HEX CAP

52 5CM1035

  • 5CM1035 - BOLT

53 28CM1050

  • 28CM1050 - BOLT

54 28E6

  • 28E6 - WASHER

55 29CM820

  • 29CM820 - SCREW FLNGE HEX CAP

56 30H57

  • 30H57 - CLAMP

57 42H48

  • 42H48 - CLAMP 5

58 43DM8

  • 43DM8 - NUT FLANGED HEX

59 43DM10

  • 43DM10 - NUT FLANGED HEX

60 51DM8

  • 51DM8 - NUT HX THDLK PREAPPL

61 6684520

  • 6684520 - NUT

62 6589675

  • 6589675 - SCREW

63 6902929

  • 6902929 - INSTRUCTIONS
