BUMPER 6597572 (1)
1 6597572
- 6597572 - BUMPER
2 6628002
- 6628002 - PIN
3 6628547
- 6628547 - WASHER
4 6668787
- 6668787 - RING
- SNAP
5 6675859
- 6675859 - RETAINER
6 6676204
- 6676204 - NUT
7 6676724
- 6676724 - FRAME LIGHT
- Was 6676203
8 6667934
- 6667934 - LIGHT
- BULB
9 6675938
- 6675938 - LIGHT
- SEALED BEAM
- W/pigtail - Use W/Ref. 7
10 6812687
- 6812687 - WASHER
11 6812713
- 6812713 - RING
12 7134105
- 7134105 - BOOM
- ARM DIPPER
- Also Order Ref. 12 - Was 7102816
13 6813497
- 6813497 - BUSHING
14 6813863
- 6813863 - PIN
15 6813932
- 6813932 - WASHER
16 6813933
- 6813933 - WASHER
17 6814280
- 6814280 - PIN
18 10H25
- 10H25 - FTG GREASE STRAIGHT
- straight
19 28CM820
- 28CM820 - BOLT CARRIAGE 8.8
- Was 21CM820
20 51DM8
- 51DM8 - NUT HX THDLK PREAPPL
- Was 4DM8
21 53CM2450
- 53CM2450 - SCREW
22 7135896
- 7135896 - HARNESS
- work light - 156" (3962 mm) long
23 6692400
- 6692400 - BULB
24 6691410
- 6691410 - LIGHT
- W/O pigtail - Use W/Ref. 23
25 7236811
- 7236811 - HOUSING
- W/A
26 1CM655
- 1CM655 - SCREW
- for light W/O pigtail
27 17C532
- 17C532 - BOLT 5
- for light W/pigtail
28 51DM6
- 51DM6 - NUT HX THDLK PREAPPL
- for light W/O pigtail
29 61D5
- 61D5 - NUT HEX FINISHED GR5
- for light W/pigtail
30 7135981
- 7135981 - HARNESS
- extension - 6" (152mm) long
31 6597688
- 6597688 - PLATE
- 3.86" (98
- 0 mm) wide - weld on - Use W/Ref. 11 (7134105 boom)
32 6628560
- 6628560 - BRACKET
- 2.95" (74
- 9 mm) wide - weld on - Use W/Ref. 11 (NLA/7102816 boom)
33 6610510
- 6610510 - STRAP
- TIE 10
