PROPSHAFT FRONT ASSY 7258984 (3)

PROPSHAFT FRONT ASSY 7258984 (3)

PROPSHAFT FRONT ASSY 7258984 (3)

1 7258984

  • 7258984 - PROPSHAFT FRONT ASSY
  • W/ Ref. 2-6

2 7258985

  • 7258985 - SHAFT
  • PROP FRONT

3 7252868

  • 7252868 - KIT
  • CROSS AND BEARING NONGREASE

4 7252867

  • 7252867 - YOKE

5 7252869

  • 7252869 - YOKE

6 10H35

  • 10H35 - FTG GREASE STRAIGHT

7 7258986

  • 7258986 - PROPSHAFT REAR ASSY
  • W/ Ref. 3 & 6-10

8 7258987

  • 7258987 - SHAFT
  • PROP REAR

9 7258297

  • 7258297 - YOKE

10 7258988

  • 7258988 - BEARING ASSY

11 7016642

  • 7016642 - SCREW

12 7016518

  • 7016518 - NUT

13 7258989

  • 7258989 - WASHER

14 7016543

  • 7016543 - PIN
  • SPRING
