641.0
/
WIRE 6560117 (1)

WIRE 6560117 (1)

WIRE 6560117 (1)

1 6560117

  • 6560117 - WIRE

2 742876

  • 742876 - GROMMET

3 6562606

  • 6562606 - SEAL

4 87G1010

  • 87G1010 - SCREW
  • Was 85G001010B

5 6563210

  • 6563210 - SENDER
  • Fuel - includes gasket

6 42HS04

  • 42HS04 - CLAMP HOSE TYPE M
  • Was 6515575

7 6559717

  • 6559717 - HOSE

8 6562546

  • 6562546 - HOSE

9 6562559

  • 6562559 - BAND

10 6661114

  • 6661114 - CAP
  • DIESEL 1 PSI
  • Green - Was 6632468

11 6661696

  • 6661696 - CAP
  • FUEL LOCKING
  • locking - W/Ref. 51 - Code PK510

12 6591273

  • 6591273 - STRIPBULK
  • rubber - bulk - Was 6563233

13 6562548

  • 6562548 - TUBE

14 6559447

  • 6559447 - WASHER
  • square

15 84G3716

  • 84G3716 - SCREW THD ROLLING TT

16 62F4

  • 62F4 - ELBOW

17 6562553

  • 6562553 - VALVE
  • shut-off

18 6515682

  • 6515682 - PLUG

19 6515466

  • 6515466 - WASHER 5

20 6515468

  • 6515468 - WASHER

21 61D5

  • 61D5 - NUT HEX FINISHED GR5

22 6562402

  • 6562402 - BRACKET

23 10C512

  • 10C512 - BOLT SQ NECK RND HD
  • Was 6553808

24 61D6

  • 61D6 - NUT HEX FINISHED GR5

25 25K20014

  • 25K20014 - O RING 10

26 6560355

  • 6560355 - FITTING

27 6562425

  • 6562425 - HOSE

28 6513471

  • 6513471 - CLAMP

29 2FM12155

  • 2FM12155 - WASHER

30 6511033

  • 6511033 - CONNECTOR
  • banjo

31 6666396

  • 6666396 - SCREW
  • hollow - Was 6514745

32 6558246

  • 6558246 - HOSE

33 17C616

  • 17C616 - BOLT 5

34 6558639

  • 6558639 - HOSE

35 6515603

  • 6515603 - GROMMET

36 6505813

  • 6505813 - ADAPTER

37 6563131

  • 6563131 - HOSE

38 6563132

  • 6563132 - TUBE

39 17C512

  • 17C512 - BOLT 5

40 30H15

  • 30H15 - CLIP

41 6555921

  • 6555921 - BOLT
  • hollow

42 1303932

  • 1303932 - GROMMET
  • Was 1318291

43 6513763

  • 6513763 - WASHER
  • Was 2FM14180B

44 6511899

  • 6511899 - INSERT
  • banjo

45 6630972

  • 6630972 - GASKET

46 6654374

  • 6654374 - 2 KEYS
  • Code GC020

47 6587458

  • 6587458 - KEY CAP FUEL 2
  • Code PK510
