Bobcat
/
730.0
/
PUMP 6512389

PUMP 6512389

PUMP 6512389

1 6512389

  • 6512389 - PUMP
  • Ref. 3 - 11 - Was 6513185

2 6516640

  • 6516640 - NOZZLE
  • oil spray

3 6516638

  • 6516638 - GEAR

4 8D7

  • 8D7 - NUT

5 6516645

  • 6516645 - GASKET
  • oil pump cover

6 85G1004

  • 85G1004 - SCREW
  • Was 86G001004B

7 21E10

  • 21E10 - WASHER

8 6516650

  • 6516650 - SCREEN

9 6516637

  • 6516637 - SCREW
  • lock - Oil Pump

10 16F2

  • 16F2 - PLUG
  • Was 15F-2
