BOLT 18C818
1 18C818
- 18C818 - BOLT
2 3725482
- 3725482 - SHIM
3 3725481
- 3725481 - T WASHER
4 3725480
- 3725480 - WASHER
5 6649434
- 6649434 - GEAR
- camshaft
6 3725483
- 3725483 - WASHER
- Was 3725483
7 873222
- 873222 - PIN
- Was 3725484B
8 6J807
- 6J807 - KEY
- WOODRUFF
9 6649432
- 6649432 - BOLT
10 4E5
- 4E5 - WASHER
11 6513099
- 6513099 - BACK PLT
12 6668034
- 6668034 - GASKET
- Was 6649431
13 18C510
- 18C510 - BOLT
14 3490221
- 3490221 - WASHER
15 6511209
- 6511209 - NECK
16 6668021
- 6668021 - GASKET
- Was 3490369B
17 7013155
- 7013155 - BEARING PLATE
- Was 3490179
18 6911870
- 6911870 - BUSH
- Was 3490181
19 3725486
- 3725486 - GEAR
- idler - W/Ref. 19
20 3725424
- 3725424 - CAP
- oil
21 6649435
- 6649435 - BOLT
22 17C408
- 17C408 - BOLT
23 3490238
- 3490238 - WASHER
24 6510642
- 6510642 - BUSHING
- cam
25 3737800
- 3737800 - DOWEL PIN
26 3737966
- 3737966 - GEAR
- pump
27 4E6
- 4E6 - WASHER
28 18C616
- 18C616 - BOLT 5
29 18C540
- 18C540 - BOLT
30 6660651
- 6660651 - GASKET
- also Order 6660650 plate
31 3739127
- 3739127 - PIN
- engine timing
32 6660650
- 6660650 - PLATE
33 6924348
- 6924348 - SEAL OIL FRONT
- Was 3738154
34 3490223
- 3490223 - WASHER
- flat
35 6674361
- 6674361 - COVER
- Was 6662836
36 6667832
- 6667832 - GASKET
- GEARCASE
- Was 3725500B
37 6649438
- 6649438 - WASHER
- thrust - Use only when new cylinder block
- old camshaft
- gear & timing case gasket are used
38 18C512
- 18C512 - BOLT
39 4E5
- 4E5 - WASHER
