MOTOR, TRAVEL 7027485

MOTOR, TRAVEL 7027485

MOTOR, TRAVEL 7027485

1 7027485

  • 7027485 - MOTOR
  • TRAVEL
  • Ref. 2-48 & 51-53

2 7261580

  • 7261580 - HUB
  • Ref. 3-23

3 6667751

  • 6667751 - HOUSING

4 6667786

  • 6667786 - SPOOL

5 6667784

  • 6667784 - SPRING

6 6667777

  • 6667777 - O-RING

7 6667788

  • 6667788 - WASHER

8 6667787

  • 6667787 - BOLT

9 6667779

  • 6667779 - O-RING

10 6688111

  • 6688111 - PIN

11 6667781

  • 6667781 - BEARING

12 6667782

  • 6667782 - DOWEL PIN

13 6667778

  • 6667778 - PISTON
  • MOTOR TRAVEL

14 6667775

  • 6667775 - PLATE
  • swash

15 6667776

  • 6667776 - DOWEL PIN

16 6667774

  • 6667774 - SEAL

17 6667789

  • 6667789 - HOUSING

18 6667772

  • 6667772 - SHAFT

19 6667756

  • 6667756 - SNAP RING

20 6667773

  • 6667773 - BEARING

21 6667762

  • 6667762 - SNAP RING

22 6667754

  • 6667754 - BEARING
  • W/floating seal

23 6658401

  • 6658401 - O-RING
  • Incl. W/Ref. 49 & 50 - Was 6667769

24 6667770

  • 6667770 - BEARING

25 6667765

  • 6667765 - SNAP RING

26 6667748

  • 6667748 - HOUSING

27 6667792

  • 6667792 - GEAR ASSEMBLY
  • Ref. 31-36

28 6693116

  • 6693116 - PIN

29 6667757

  • 6667757 - WASHER

30 7261585

  • 7261585 - GEAR

31 6667760

  • 6667760 - BEARING
  • needle

32 6667758

  • 6667758 - WASHER

33 6667759

  • 6667759 - SNAP RING

34 6693115

  • 6693115 - PIN

35 7261582

  • 7261582 - CARRIER
  • MOTOR

36 7261583

  • 7261583 - GEAR

37 7261589

  • 7261589 - BEARING
  • NEEDLE

38 7261586

  • 7261586 - GEAR
  • SUN

39 6667764

  • 6667764 - SNAP RING

40 7261584

  • 7261584 - GEAR SUN

41 7261588

  • 7261588 - O-RING

42 7261587

  • 7261587 - SPACER

43 6688096

  • 6688096 - COVER

44 6676161

  • 6676161 - PLUG

45 6667767

  • 6667767 - SNAP RING

46 6667791

  • 6667791 - SEAL KIT
  • Ref. 7
  • 11
  • 18
  • 25 & 44

47 7310948

  • 7310948 - KIT PLUG

48 6667790

  • 6667790 - KIT
  • SEAL
  • Ref. 24 & 49

49 7308583

  • 7308583 - KIT UNIVERSAL PLUG

50 6688119

  • 6688119 - KIT
  • shim
