NUT 6676169 (1)

NUT 6676169 (1)

NUT 6676169 (1)

1 6676169

  • 6676169 - NUT

2 7009353

  • 7009353 - CLAMP
  • T-BOLT

3 7174256

  • 7174256 - BRACKET
  • VALVE

4 79K6

  • 79K6 - O RING 10

5 7185275

  • 7185275 - FITTING
  • HYD TEE

6 7189078

  • 7189078 - VALVE
  • LOCK LOAD

7 7196470

  • 7196470 - TUBELINE
  • HYD

8 7196618

  • 7196618 - TUBELINE
  • HYD

9 7196714

  • 7196714 - HOSE
  • HYD

10 7196820

  • 7196820 - HOSE
  • HYD

11 7259342

  • 7259342 - BRACKET

12 7011053

  • 7011053 - CLIP

13 78K6

  • 78K6 - O'RING

14 10L0606

  • 10L0606 - FITTING
  • HYD CONNECTOR

15 79K8

  • 79K8 - O RING 10

16 15KB0608

  • 15KB0608 - FITTING
  • HYD CONNECTOR

17 79K4

  • 79K4 - O RING 10

18 17KB0404

  • 17KB0404 - FTG HYD ELBOW 90

19 79K6

  • 79K6 - O RING 10

20 17KB0406

  • 17KB0406 - FITTING
  • HYD ELBOW

21 79K4

  • 79K4 - O RING 10

22 21KB0404

  • 21KB0404 - FITTING
  • HYD TEE
  • Use W/Arm Load Hold

23 29CM820

  • 29CM820 - SCREW FLNGE HEX CAP

24 36K3

  • 36K3 - CAP
  • Use W/O Arm Load Hold

25 51DM8

  • 51DM8 - NUT HX THDLK PREAPPL

26 53CM855

  • 53CM855 - SCREW

27 79K4

  • 79K4 - O RING 10

28 15KB0404

  • 15KB0404 - FTG HYD S CONNECTOR
  • Use W/O Arm Load Hold
