STARTER 7253205 (3)

STARTER 7253205 (3)

STARTER 7253205 (3)

1 7253205

  • 7253205 - STARTER

2 6672178

  • 6672178 - COVER

3 6674818

  • 6674818 - ARMATURE
  • W/Ref. 4 & 6

4 6672000

  • 6672000 - RETAINER

5 6671982

  • 6671982 - O-RING

6 6671999

  • 6671999 - ROLLER

7 6672008

  • 6672008 - NUT

8 6672007

  • 6672007 - BUSHING
  • drain

9 6671991

  • 6671991 - SPRING
  • compression

10 6674821

  • 6674821 - CLUTCH
  • W/Ref. 24-25

11 6672013

  • 6672013 - O-RING

12 6672006

  • 6672006 - NUT

13 6672001

  • 6672001 - PINION

14 6672172

  • 6672172 - DRIVEGEAR
  • starter

15 6666631

  • 6666631 - O-RING

16 6674831

  • 6674831 - SPRING
  • compression oil

17 6672011

  • 6672011 - NUT

18 6672012

  • 6672012 - WASHER

19 6671997

  • 6671997 - BOLT
