NUT 7030370

NUT 7030370

NUT 7030370

1 7030370

  • 7030370 - NUT

2 7249380

  • 7249380 - PUMP
  • FUEL INJ
  • W/Ref. 9 & 10 - Was 7030405

3 7030412

  • 7030412 - O-RING

4 7249381

  • 7249381 - COLLAR
  • Was 7030315

5 7030413

  • 7030413 - O-RING

6 7030347

  • 7030347 - GEAR
  • DRIVE

7 7030372

  • 7030372 - NUT
  • FLANGE

8 7249447

  • 7249447 - STUD
  • Was 7030286

9 7256772

  • 7256772 - VALVE INLET METER

10 7253204

  • 7253204 - SENSOR
  • FUEL TEMP
