RING, SNAP 6662076 (3)

RING, SNAP 6662076 (3)

RING, SNAP 6662076 (3)

1 6662076

  • 6662076 - RING
  • SNAP

2 6674221

  • 6674221 - WASHER

3 6810029

  • 6810029 - STOP
  • SWIVEL

4 7100535

  • 7100535 - SEAL
  • DUST
  • Was 6810610

5 6810813

  • 6810813 - SEAL
  • OIL
  • 2 pc seal

6 6812171

  • 6812171 - PLUG

7 79K6

  • 79K6 - O RING 10

8 6679248

  • 6679248 - BACKUP RING
  • Use W/Ref. 6 on spool W/ 4
  • 44 mm (.175") groove height in the first & fifth O-ring grooves from the top
