SWITCH WIPER 6671113 (1)

SWITCH WIPER 6671113 (1)

SWITCH WIPER 6671113 (1)

1 6671113

  • 6671113 - SWITCH WIPER

2 7228598

  • 7228598 - PLUG
  • if equipped

3 6676114

  • 6676114 - ANTENNA
  • RADIO

4 6682697

  • 6682697 - GROMMET

5 6903211

  • 6903211 - SPEAKER
  • 4 INCH
  • - Was 6685606

6 6685607

  • 6685607 - GRILLE

7 6685744

  • 6685744 - NUT

8 7142762

  • 7142762 - CLIP

9 7163690

  • 7163690 - SCREW

10 7166629

  • 7166629 - LIGHT
  • CAB HEADLINER
  • 2 position switch - Use W/ 7179100 headliner & Ref. 11 (7171741 harness)

11 7229539

  • 7229539 - LIGHT
  • CAB HEADLINER
  • Use W/ 7232300 headliner & Ref. 11 (7232548 harness) or W/ 7232868 headliner & Ref. 11 (7225809 harness)

12 7170114

  • 7170114 - SCREW

13 7171741

  • 7171741 - HARNESS
  • CAB
  • Use W/ 7179100 harness & Ref. 9 (7166629 light)

14 7232548

  • 7232548 - HARNESS
  • CAB
  • Use W/ 7232300 headliner & Ref. 9 (7229539 light)

15 7225809

  • 7225809 - HARNESS
  • CAB
  • Use W/ 7232868 headliner & Ref. 9 (7229539 light)

16 7171777

  • 7171777 - HARNESS
  • WIPER
