TENSIONER, TRACK ASSY 7180664 (1)
1 7180664
- 7180664 - TENSIONER
- TRACK ASSY
- Ref. 2-5
- 10-13
- & 15
2 25K30118
- 25K30118 - O RING 10
- Was 54K30118
3 7135356
- 7135356 - SHAFT
- CHROME
4 6686968
- 6686968 - SEAL
- WIPER ROD
5 6685154
- 6685154 - RING
- BACK-UP
6 6672338
- 6672338 - O-RING
7 7000773
- 7000773 - RING
- WEAR
- .75" (19
- 05 mm) wide - Use W/Ref. 1 (NLA/ 7152280 tensioner)
8 6655752
- 6655752 - FITTING
- GREASE
- 68
- 900 kpa (10
- 000 psi) - DO NOT SUBSTITUTE
9 6645812
- 6645812 - SCREW
- BLD
10 6688839
- 6688839 - WEAR RING
- 9
- 53 mm (0.38") wide - Use W/Ref. 1 (7180664 tensioner)
11 7180324
- 7180324 - TUBE
- GREASE
- Use W/Ref. 1 (7180664 tensioner)
12 7163219
- 7163219 - KIT
- SEAL
- Ref. 5-8 & 12
