ROTOR ASSEMBLY 7023575

ROTOR ASSEMBLY 7023575

ROTOR ASSEMBLY 7023575

1 7023575

  • 7023575 - ROTOR ASSEMBLY
  • Ref. 2-11

2 7023593

  • 7023593 - TOOL TOOTH
  • 84 mm (3.3125") tall

3 7023592

  • 7023592 - BOLT

4 7023591

  • 7023591 - BOLT

5 7023606

  • 7023606 - HOLDER
  • TOOL
  • weld-on - W/Ref. 6

6 7023607

  • 7023607 - BUSHING
  • pressed into Ref. 5

7 7023590

  • 7023590 - WASHER

8 6692609

  • 6692609 - SHAFT

9 6692608

  • 6692608 - BOLT

10 7020618

  • 7020618 - WASHER

11 7023725

  • 7023725 - ROTOR
  • W/Ref. 5 & 6

12 7328985

  • 7328985 - TOOL KNIFE
