NUT 000345-96E (3)

NUT 000345-96E (3)

NUT 000345-96E (3)

1 000345-96E

  • 000345-96E - NUT

2 00350-03W

  • 00350-03W - WASHER

3 000350-04X

  • 000350-04X - WASHER
  • M12

4 01528.9

  • 01528.9 - Screw

5 4CM816

  • 4CM816 - SCREW HEX HD 8.8

6 4CM820

  • 4CM820 - SCREW HEX HD 8.8

7 1CM1025

  • 1CM1025 - BOLT

8 1CM1040

  • 1CM1040 - BOLT

9 2GM1030

  • 2GM1030 - SCREW SOCKET HD CAP

10 01718.6

  • 01718.6 - Washer

11 7299361

  • 7299361 - CAP
  • HYD

12 13399.1

  • 13399.1 - Screw

13 14039.2

  • 14039.2 - Screw

14 1CM1650

  • 1CM1650 - SCREW

15 38441.2

  • 38441.2 - Union

16 54009.6

  • 54009.6 - Screw

17 7225260

  • 7225260 - WASHER

18 89517.7

  • 89517.7 - Washer

19 7235680

  • 7235680 - WASHER FLAT

20 89519.3

  • 89519.3 - Washer

21 96461.9

  • 96461.9 - Adapter

22 96462.7

  • 96462.7 - Drain Hose

23 97878.3

  • 97878.3 - Housing

24 7193303

  • 7193303 - SPRING

25 98272.8

  • 98272.8 - Spring

26 7252655

  • 7252655 - NUT LOCK

27 6908071

  • 6908071 - SUPPORT

28 6908663

  • 6908663 - PLATE

29 7172531

  • 7172531 - HOLDER

30 6919322-NREG

  • 6919322-NREG - ENGINE PERKINS

31 6921134

  • 6921134 - PIPE INTAKE

32 6921192

  • 6921192 - BLOCK SILENT

33 6922321

  • 6922321 - BLOCK SILENT

34 6923517

  • 6923517 - INLET SEAL

35 01591.7

  • 01591.7 - Screw

36 100345-06W

  • 100345-06W - NUT

37 7172528

  • 7172528 - HOLDER

38 6910328

  • 6910328 - BRACKET
  • SPRING ANCHORING

39 01697.2

  • 01697.2 - Washer

40 007330-29V

  • 007330-29V - SCREW HM8-30/30 CL 8.8 ZJ 8

41 29713.5

  • 29713.5 - Clamp

42 35949.7

  • 35949.7 - Clamp

43 38683.9

  • 38683.9 - Collar

44 01681.6

  • 01681.6 - Nut

45 97746.2

  • 97746.2 - Air Filter

46 7166418

  • 7166418 - HOLDER AIR FILTER

47 7165319

  • 7165319 - INLET AIR RAIN CAP

48 7171124

  • 7171124 - SENSOR

49 6916705

  • 6916705 - HOSE

50 6916706

  • 6916706 - HOSE

51 6910724

  • 6910724 - HOUSING

52 6910725

  • 6910725 - FILTER
  • AIR OUTER

53 6910726

  • 6910726 - FILTER
  • AIR INNER

54 6910727

  • 6910727 - RING

55 6913087

  • 6913087 - SENSOR
  • ENGINE SPEED TIER II

56 98132.4

  • 98132.4 - Washer
