RAM 92242-7 (1)

RAM 92242-7 (1)

RAM 92242-7 (1)

1 92242-7

  • 92242-7 - RAM

2 6909363

  • 6909363 - VALVE

3 56028-4

  • 56028-4 - PLUG
  • MALE 1/4 BSPP 6 P.CREU

4 93131-1

  • 93131-1 - SEAL KIT

5 78743-2

  • 78743-2 - PLUG

6 6GM840

  • 6GM840 - SCREW

7 7244882

  • 7244882 - FITTING HYDRAULIC

8 7244942

  • 7244942 - FITTING HYDRAULIC CONNECTOR

9 6908571

  • 6908571 - HOSE TJ 7/8 12
  • 7 TJ 7/8 L865

10 70224-1

  • 70224-1 - HOSE

11 014375-02C

  • 014375-02C - UNION 7/8 JIC 3/4 BSPP

12 6908552

  • 6908552 - VALVE
  • CONTROL

13 88713-3

  • 88713-3 - PIN

14 65397-2

  • 65397-2 - SCREW

15 7252655

  • 7252655 - NUT LOCK

16 008372-28F

  • 008372-28F - UNION

17 6908623

  • 6908623 - TUBE HYDRAULIC V518

18 6908624

  • 6908624 - TUBE HYDRAULIC V518

19 010370-94B

  • 010370-94B - ELBOW PIECE

20 88741-4

  • 88741-4 - CYLINDER

21 88739-8

  • 88739-8 - SILENT BLOCK

22 52294-6

  • 52294-6 - SCREW

23 100345-14F

  • 100345-14F - NUT

24 009456-02D

  • 009456-02D - WASHER

25 100375-39T

  • 100375-39T - UNION 7/8 JIC 3/8 BSP

26 98235-5

  • 98235-5 - BAL.VALVE

27 7229423

  • 7229423 - FITTING

28 70331-4

  • 70331-4 - HOSE

29 1CM840

  • 1CM840 - SCREW HEX CAP

30 89519-3

  • 89519-3 - WASHER

31 100372-22Z

  • 100372-22Z - UNION

32 100375-43X

  • 100375-43X - REDUCER
