SHOVEL, LOADING CPL. 6453201000

SHOVEL, LOADING CPL. 6453201000

SHOVEL, LOADING CPL. 6453201000

1 6453201000

  • 6453201000 - SHOVEL
  • LOADING CPL.
  • 1950MM - Ref. 2 & 8-15

2 0453201001

  • 0453201001 - SHOVEL
  • LOADING
  • 1950MM - W/Ref. 3-7

3 6397201004

  • 6397201004 - SIDE-STRIP

4 0453201023

  • 0453201023 - EDGE
  • CUTTING RIGHT

5 0453201024

  • 0453201024 - EDGE
  • CUTTING LEFT

6 6337201205

  • 6337201205 - EDGE
  • CUTTING
  • W/Ref. 7

7 5455204900

  • 5455204900 - SLEEVE

8 5455204800

  • 5455204800 - TOOTH

9 5455700096

  • 5455700096 - TOOTH CUP
  • Was 5455205000

10 6453201030

  • 6453201030 - COVER
  • W/Ref. 11-13

11 5249001010

  • 5249001010 - SPRING

12 1395707827

  • 1395707827 - COTTER PIN
  • Was 5249001011

13 1940000739

  • 1940000739 - RIVET

14 6453202000

  • 6453202000 - SHOVEL
  • LOADING
  • 1950MM - Ref. 10-17 & 19-22

15 0453202001

  • 0453202001 - SHOVEL
  • LOADING
  • 1950MM - W/Ref. 3-5 & 18

16 0453202003

  • 0453202003 - EDGE
  • CUTTING

17 0453202002

  • 0453202002 - BOLT-ON
  • CUTTING EDGE

18 1062707236

  • 1062707236 - BOLT
  • M 14X50

19 1290707025

  • 1290707025 - WASHER
  • 15

20 1212251015

  • 1212251015 - NUT
  • M 14
