(B90B) - BACKHOE LOADER - TIER 3 (11/10-)
/
STEERING VALVE 84323345

STEERING VALVE 84323345

STEERING VALVE 84323345

1 84323345

  • 84323345 - STEERING VALVE

2 84323353

  • 84323353 - STEERING VALVE

3 85805775

  • 85805775 - COVER

4 85805774

  • 85805774 - COVER

5 10615774

  • 10615774 - WASHER

6 14432334

  • 14432334 - HEX SOC SCREW
  • M10 x 1.5 x 22mm
  • Cl 10.9
  • Full Thd

7 14303324

  • 14303324 - HEX SOC SCREW
  • M4 x 20mm
  • Cl 8.8
  • Full Thd

8 11190574

  • 11190574 - BELLEVILLE WASHER
  • M10 Bolt Size x 20mm OD x 2.3mm Thk

9 86624176

  • 86624176 - WASHER
  • 11mm ID x 20mm OD x 2mm Thk

10 15970724

  • 15970724 - SCREW
  • Hex
  • M10 x 1.25 x 25mm
  • Cl 8.8
  • Full Thd

11 43140

  • 43140 - BOLT
  • Hex
  • M10 x 1.5 x 30mm
  • Cl 8.8

12 85820105

  • 85820105 - CAP

13 85805772

  • 85805772 - COVER

14 5148946

  • 5148946 - STEERING WHEEL

15 4998760

  • 4998760 - WASHER
  • 17.2mm ID x 32mm OD x 3.5mm Thk

16 10791414

  • 10791414 - THIN NUT
  • M16 x 1.5

17 85801976

  • 85801976 - BOOT

18 14568887

  • 14568887 - FASTENER
  • M8 x 0.7 x 29mm

19 10791423

  • 10791423 - THIN NUT
  • M16 x 1.5
  • Cl 05

20 15688107

  • 15688107 - SELF-TAP SCREW
  • M4.2 x 16mm
