(DC150PS) - CRAWLER DOZER
/
SENSOR

SENSOR

SENSOR

1 79113969

  • 79113969 - SENSOR

2 76071275

  • 76071275 - WIRE HARNESS

3 76069679

  • 76069679 - BRACKET

4 4982514

  • 4982514 - CABLE TIE

5 11106231

  • 11106231 - BOLT
  • Hex
  • M10 x 1.5 x 25mm
  • Cl 10.9

6 14496631

  • 14496631 - WASHER
  • 10.5mm ID x 21mm OD x 2mm Thk
