(DC150PS) - CRAWLER DOZER
/
SPRING 547515

SPRING 547515

SPRING 547515

1 547515

  • 547515 - SPRING

2 569475

  • 569475 - SCREW

3 79087266

  • 79087266 - PIN

4 10734201

  • 10734201 - COTTER PIN
  • M2 x 12

5 79089244

  • 79089244 - LEVER

6 79093725

  • 79093725 - SPRING

7 79060774

  • 79060774 - BUSHING

8 76046977

  • 76046977 - SUPPORT

9 14496631

  • 14496631 - WASHER
  • 10.5mm ID x 21mm OD x 2mm Thk

10 14496531

  • 14496531 - WASHER
  • 8.4mm ID x 17mm OD x 1.6mm Thk

11 14604270

  • 14604270 - LOCK PIN
  • M6 x 32
  • Slotted

12 11701714

  • 11701714 - NUT

13 11106031

  • 11106031 - BOLT
  • Hex
  • M10 x 1.5 x 20mm
  • Cl 10.9

14 14420631

  • 14420631 - HEX SOC SCREW
  • M10 x 1.5 x 50mm
  • Cl 10.9

15 79078966

  • 79078966 - SHAFT

16 76069834

  • 76069834 - TIE-ROD

17 76054843

  • 76054843 - PEDAL

18 79085368

  • 79085368 - LEVER

19 76073357

  • 76073357 - LEVER

20 79080389

  • 79080389 - IDLER LEVER

21 79086637

  • 79086637 - SCREW
  • Rd Slotted
  • M8 x 1.25 x 32mm L

22 16100814

  • 16100814 - NUT
  • M8
  • Cl 8
  • DAC
