(DC150PS) - CRAWLER DOZER
/
SUPPORT 76046806

SUPPORT 76046806

SUPPORT 76046806

1 76046806

  • 76046806 - SUPPORT

2 79048068

  • 79048068 - ROLLER BEARING
  • 20 mm ID x 26 mm OD x 16 mm

3 79102461

  • 79102461 - PIN

4 11701721

  • 11701721 - NUT
  • M10
  • Cl 10

5 11106031

  • 11106031 - BOLT
  • Hex
  • M10 x 1.5 x 20mm
  • Cl 10.9

6 11106424

  • 11106424 - SCREW
  • Hex
  • M10 x 30mm
  • Cl 8.8
  • Full Thd

7 12626231

  • 12626231 - WASHER
  • 10.2mm ID x 25mm OD x 3mm Thk

8 76046804

  • 76046804 - FOOTREST

9 15214931

  • 15214931 - BOLT
  • Hex
  • M10 x 1.5 x 65mm
  • Cl 10.9
  • Full Thd
