(E80) - MIDI CRAWLER EXCAVATOR ASN LF04-02346 (N5TA18048) (NA) (1/06-)
/
VALVE YR30V00014F1 (2)

VALVE YR30V00014F1 (2)

VALVE YR30V00014F1 (2)

1 YR30V00014F1

  • YR30V00014F1 - VALVE
  • CONTROL (DOZER)
  • See Figure 190

2 YT64H01026P1

  • YT64H01026P1 - BRACKET

3 ZS18C12035

  • ZS18C12035 - SCREW
  • Hex
  • M12 x 35mm

4 ZS28C08035

  • ZS28C08035 - SCREW
  • Hex Socket Head
  • M8 x 35mm
  • CAPSCREW

5 ZW16H08000

  • ZW16H08000 - WASHER
  • ID 08 x OD 18 x Th 3.2mm

6 ZW16H12000

  • ZW16H12000 - WASHER

7 ZN18C08007

  • ZN18C08007 - NUT
  • M08x1.25mm
