(W60C) - COMPACT WHEEL LOADER STD, TC - TIER 4 (6/14-)
/
SUPPORT 47680706

SUPPORT 47680706

SUPPORT 47680706

1 47680706

  • 47680706 - SUPPORT

2 47679890

  • 47679890 - BRACKET

3 43233

  • 43233 - BOLT
  • Hex
  • M8 x 1.25 x 20mm
  • Full Thd
  • Cl 10.9

4 86624184

  • 86624184 - WASHER
  • 9mm ID x 16mm OD x 1.6mm Thk

5 47707174

  • 47707174 - SUPPORT
  • License

6 10902831

  • 10902831 - SCREW
  • Hex
  • M6 x 30mm
  • Cl 10.9

7 86588450

  • 86588450 - WASHER
  • 6.6mm ID x 12mm OD x 1.6mm Thk

8 86500688

  • 86500688 - NUT
  • Hex
  • M6 x 1.0
  • Cl 10.9
