FRONT PANEL WELDMENT 102221301CC
1 102221301CC
- 102221301CC - FRONT PANEL WELDMENT
- assy - W/Ref. 2
2 101553901CC
- 101553901CC - DECAL
- WARNING
- bed load
3 102221401CC
- 102221401CC - PANEL WELDMENT LH
- driver side
4 102221501CC
- 102221501CC - RIGHT PANEL WELDMENT
- passenger side
5 1015399CC
- 1015399CC - SCREW
- 5/16-18 X .88 TRX TRUSS
6 7473CC
- 7473CC - LOCKNUT
- 5/16-18 NYLON INSERT
7 1010435CC
- 1010435CC - BOLT
- 5/16-18 X 1.00 SQ.NECK
8 332CC
- 332CC - WASHER
- 1/4 TYPE A NARROW FLAT
9 102222001CC
- 102222001CC - SLAM LATCH
10 1010436CC
- 1010436CC - RUBBER BUMPER
11 102229908CC
- 102229908CC - TAILGATE
- assy - Ref. 12-20 assy - Ref. 12 - 20 - Was 102229902CC
12 102222101CC
- 102222101CC - SPRING
- LATCH
- passenger side
13 102222201CC
- 102222201CC - SPRING
- LATCH
- driver side
14 8419CC
- 8419CC - SCREW
15 332CC
- 332CC - WASHER
- 1/4 TYPE A NARROW FLAT
16 8233CC
- 8233CC - LOCKNUT
- 1/4-20 NYLON INSERT
17 102221801CC
- 102221801CC - TETHER ASSEMBLY
18 1013366CC
- 1013366CC - PIN
19 102339001CC
- 102339001CC - DECAL TAILGATE
- Bobcat - tailgate
20 101894304CC
- 101894304CC - BOX BED TAILGATE ANGLE
- tailgate angle
21 1014537CC
- 1014537CC - STUD
- SELF-CLINCHING FLUSH HD.
22 101963401CC
- 101963401CC - LOCKNUT
- 5/16-18 HEX FLANGE
23 1014415CC
- 1014415CC - SCREW
- 1/4-20 X .75 TORX TRUSS
24 1014306CC
- 1014306CC - WASHER
- 1/4" TYPE B FLAT
25 8233CC
- 8233CC - LOCKNUT
- 1/4-20 NYLON INSERT
26 102221701CC
- 102221701CC - FRONT CORNER CAP
27 102239901CC
- 102239901CC - WASHER
28 102230602CC
- 102230602CC - KIT STEEL BOX
- NLA - steel box - Ref. 1-28 - Was 102230602CC
