Bobcat
/
2100
/
KIT, WINCH 103253101CC

KIT, WINCH 103253101CC

KIT, WINCH 103253101CC

1 103253101CC

  • 103253101CC - KIT
  • WINCH
  • W/Ref. 2-30 - must have 103273901CC front receiver installed to mount winch

2 103212301CC

  • 103212301CC - BRACKET
  • Was 103212301CC

3 102718301CC

  • 102718301CC - PIN

4 2F5062

  • 2F5062 - PIN

5 357CC

  • 357CC - WASHER
  • 3/8 SPLIT LOCK

6 1010934CC

  • 1010934CC - SCREW
  • 5/16-18 X 1.00 HEX CAP
  • Was 17C516

7 17C612

  • 17C612 - SCREW HEX CAP

8 102673601CC

  • 102673601CC - SOCKET REMOTE CONTROL WINCH

9 103394801CC

  • 103394801CC - WINCH
  • ELEC
  • Was 103216301CC

10 6624289

  • 6624289 - STRAP
  • TIE

11 63D6

  • 63D6 - NUT

12 102673701CC

  • 102673701CC - REMOTE CONTROL 10 FT WINCH

13 1CM1020

  • 1CM1020 - SCREW HEX CAP

14 183CC

  • 183CC - WASHER
  • TYPE A FLAT

15 1017CC

  • 1017CC - NUT
  • Was 4DM10

16 25E13

  • 25E13 - WASHER FLAT PLAIN

17 451CC

  • 451CC - LOCKWASHER
  • 1/4 HELICAL SPLIT

18 95D4

  • 95D4 - NUT

19 28E5

  • 28E5 - WASHER

20 332CC

  • 332CC - WASHER
  • 1/4 TYPE A NARROW FLAT
  • Was 27E4

21 102673401CC

  • 102673401CC - CONTACTOR WINCH 12 VDC

22 102231601CC

  • 102231601CC - DECAL
  • warning

23 103222401CC

  • 103222401CC - MOUNT
