SHIELD
1 6535548
- 6535548 - SHIELD
2 6655124
- 6655124 - RING
- SLEW
- Assy. - 96 Teeth on Gear
3 6628410
- 6628410 - FRT IDLER
- front
4 7CM1280
- 7CM1280 - BOLT
5 51DM12
- 51DM12 - NUT
6 55CM1235
- 55CM1235 - BOLT
7 55CM1235
- 55CM1235 - BOLT
8 6596689
- 6596689 - COVER
9 26GM10030
- 26GM10030 - SCREW SELF TAPPING
10 6813372SUB
- 6813372SUB - SPROCKET
- MOTOR DRIVE TRACK
- PAINTED
- 12 hole - Was 6811939
11 6814137
- 6814137 - SPROCKET
- MOTOR DRIVE TRACK
- 21 tooth - 9 hole - Was 6811940
12 29CM1030
- 29CM1030 - SCREW FLGD HEX CAP
13 6534234
- 6534234 - PLATE
- SLIDE
14 6596396
- 6596396 - PLATE
- guide - steel track
15 6597346
- 6597346 - COVER
16 51DM10
- 51DM10 - NUT HX THDLK PREAPPL
17 26GM10020
- 26GM10020 - SCREW HEX THRDRLG
- Self Tapping
18 6596723
- 6596723 - COVER
19 6586494
- 6586494 - PIN
- Alignment - Service Tool for Aligning Swing Bearing when Upperstructure has been Removed from Undercarriage
20 6535902
- 6535902 - BOLT
- Alignment - Service Tool for Aligning Swing Bearing when Upperstructure has been Removed from Undercarriage
21 6596688
- 6596688 - PLATE
- Drive Motor Mount - Weld-on - 9 - hole
22 18EM1224
- 18EM1224 - WASHER HARDENED PLN
23 18EM1224
- 18EM1224 - WASHER HARDENED PLN
24 55CM1225
- 55CM1225 - BOLT
25 55CM1225
- 55CM1225 - BOLT
