UPPERSTRUCTURE 6803338
1 6803338
- 6803338 - UPPERSTRUCTURE
- Frame
2 6588425
- 6588425 - CNTRWGHT
- NLA - left hand - Was 6588425
3 6588426
- 6588426 - COUNTERWEIGHT
- Right hand
4 6587895
- 6587895 - BUMPER
- Left hand
5 6588131
- 6588131 - BUMPER
- Right hand
6 1CM1630
- 1CM1630 - BOLT
7 1CM2040
- 1CM2040 - BOLT
8 6588095
- 6588095 - BUSHING
- WELD-ON
9 7CM1260
- 7CM1260 - BOLT
10 6589060
- 6589060 - BRACKET
- latch - rear door
11 29CM840
- 29CM840 - SCREW FLGD HEX CAP
12 43DM8
- 43DM8 - NUT FLANGED HEX
13 6804078
- 6804078 - BRACKET
14 29CM825
- 29CM825 - SCREW HEX HD W/F 8.8
15 6655399
- 6655399 - BUMPER
16 61D5
- 61D5 - NUT HEX FINISHED GR5
17 26GM8016
- 26GM8016 - SCREW SELF TAPPING
18 17EM80
- 17EM80 - WASHER
19 6801013
- 6801013 - PANEL
- Left hand - Was 6801012
20 6589583
- 6589583 - COVER
- Right hand - Was 6589593
21 6596723
- 6596723 - COVER
22 26GM10020
- 26GM10020 - SCREW HEX THRDRLG
23 10H25
- 10H25 - FTG GREASE STRAIGHT
24 6654139
- 6654139 - MOULDING BULK/FT
- sold per foot
25 6628677
- 6628677 - ANGLE
26 6674389
- 6674389 - LOCK
- Was 6661695
27 6587458
- 6587458 - KEY CAP FUEL 2
28 6536802
- 6536802 - WASHER
29 10EM80
- 10EM80 - WASHER
30 6800002
- 6800002 - PLATE
- Access
31 26GM8013
- 26GM8013 - BOLT
- Was 26GM08012B
32 6803380
- 6803380 - SUPPORT
- Support
33 29CM1025
- 29CM1025 - SCREW FLGD HEX CAP
34 43DM10
- 43DM10 - NUT FLANGED HEX
35 6803390
- 6803390 - INSULATION
36 6803859
- 6803859 - INSULATION
37 6803858
- 6803858 - INSULATION
38 6803857
- 6803857 - INSULATION
39 6803885
- 6803885 - PLATE
40 6807155
- 6807155 - PLATE
- Counterweight - 2" thick
- 334#
41 17C1680
- 17C1680 - BOLT
42 17C1660
- 17C1660 - BOLT
- Use W/6807155
43 61D16
- 61D16 - LCKNUT
44 28E16
- 28E16 - WASHER
45 17C648
- 17C648 - SCREW HEX CAP
- Was 17C000640B
46 61D6
- 61D6 - NUT HEX FINISHED GR5
47 6675843
- 6675843 - NUT
