337.0
/
MOUNT, X-CHANGE 6810247 (1)

MOUNT, X-CHANGE 6810247 (1)

MOUNT, X-CHANGE 6810247 (1)

1 6810247

  • 6810247 - MOUNT
  • X-CHANGE
  • Uses (2) Ref. 3 & (2) Ref. 29

2 6802703

  • 6802703 - BUSHING
  • PRESS FIT

3 6804525

  • 6804525 - SPACER

4 6804386

  • 6804386 - SPRING
  • TORSION

5 6672019

  • 6672019 - BUSHING

6 10H25

  • 10H25 - FTG GREASE STRAIGHT

7 6628547

  • 6628547 - WASHER

8 6804534

  • 6804534 - CATCH
  • X-CHANGE

9 6668787

  • 6668787 - RING
  • SNAP

10 6806587

  • 6806587 - LATCH
  • X-CHANGE KIT

11 6804969

  • 6804969 - SPRING

12 2JM1020

  • 2JM1020 - ROLL PIN
  • Spring

13 55CM1435

  • 55CM1435 - SCREW
  • Was 7CM01435B

14 6662745

  • 6662745 - SNAP RING

15 6536748

  • 6536748 - NUT
  • Lock

16 6803815

  • 6803815 - PIN

17 6805278

  • 6805278 - LINK
  • W/Ref. 3
  • 7
  • 24 & 25 - not in kit - Was 6804816

18 6807074

  • 6807074 - LEVER
  • RELEASE
  • release - Was 6803510

19 6681505

  • 6681505 - SEAL
  • Was 6672517

20 10H35

  • 10H35 - FTG GREASE STRAIGHT

21 6652943

  • 6652943 - COVER
  • grease fitting

22 6669287

  • 6669287 - SEAL
  • Dust

23 6577822

  • 6577822 - HOSE BULK
  • sold per foot

24 6668928

  • 6668928 - PIN
  • LOCK

25 6807053

  • 6807053 - PIN
  • PIVOT X-CHANGE

26 6805579

  • 6805579 - BUSHING
  • Use W/6810247 mount only
