INSTRUCTIONS 6990024 (2)

INSTRUCTIONS 6990024 (2)

INSTRUCTIONS 6990024 (2)

1 6990024

  • 6990024 - INSTRUCTIONS

2 7017577

  • 7017577 - KIT
  • FUSIBLE LINK 2MM 6MM RING

3 7017576

  • 7017576 - KIT
  • FUSIBLE LINK 1.0MM

4 7017575

  • 7017575 - KIT
  • FUSIBLE LINK 0.8 MM

5 7023470

  • 7023470 - HARNESS
  • CHASSIS
  • W/Ref. 2
  • 5
  • 6
  • 8
  • 10
  • 15-18 & All Kits

6 7020316

  • 7020316 - DECAL
  • FUSE BOX

7 7020306

  • 7020306 - PLATE
  • FUSE MOUNT

8 7016631

  • 7016631 - SCREW

9 7017643

  • 7017643 - RELAY
  • MICRO SPDT 35/20A SLD 12

10 7017469

  • 7017469 - BREAKER
  • CIRCUIT 20 AMP SEALED

11 7016309

  • 7016309 - CLIP
  • ROSEBUD

12 6707620

  • 6707620 - FUSE
  • 10A MINI 5
  • Was 7017531

13 7016245

  • 7016245 - TIE
  • CABLE

14 6707622

  • 6707622 - FUSE
  • 20A MINI 5
  • Was 7017533

15 7017545

  • 7017545 - HARNESS
  • CARGO BOX

16 7016246

  • 7016246 - TIE
  • CABLE
  • 14"
  • 355
  • 6 mm (14") long

17 7017501

  • 7017501 - COVER
  • DIAGNOSTIC W/CLIP

18 7016306

  • 7016306 - CLIP

19 7017644

  • 7017644 - RELAY
  • SPDT SERIES 301 SEALED

20 7023503

  • 7023503 - DECAL
  • FUSE

21 7017532

  • 7017532 - FUSE
  • MAIN 30 AMP

22 7017511

  • 7017511 - RESISTOR
  • DIODE 6AMP 1/4 3/16 TERM
