PLUG 6666690 (2)
1 6666690
- 6666690 - PLUG
2 6666393
- 6666393 - SEAL RING
3 6666396
- 6666396 - SCREW
4 2FM12155
- 2FM12155 - WASHER
5 6668948
- 6668948 - TUBE
- oil lubricating
6 6668887
- 6668887 - O-RING
7 6668897
- 6668897 - ADAPTER
8 6668106
- 6668106 - TUBE
- oil return
9 6666401
- 6666401 - O-RING
10 6673169
- 6673169 - FLANGE
11 6668938
- 6668938 - BOLT
12 6666508
- 6666508 - TUBE
- oil suction
13 25K30012
- 25K30012 - O RING 10
14 6680251
- 6680251 - DIPSTICK
- OIL ENG
- W/O ribs
15 6677832
- 6677832 - OIL PAN
- W/Ref. 18
- 20
- 61 & 62
16 6666394
- 6666394 - WASHER
- brass - 18 mm x 24 mm
17 6709168
- 6709168 - ELBOW
- W/Ref. 14
- 32
- 67 & 76
18 6666400
- 6666400 - PLUG
19 6677831
- 6677831 - BOLT
20 6677575
- 6677575 - TURBOCHARGER
21 6677575REM
- 6677575REM - TURBOCHARGER
- DEUTZ BF4M1011
22 6677575EF
- 6677575EF - TURBOCHARGER
23 6666510
- 6666510 - VALVE
24 6668941
- 6668941 - SPRING
- Yellow - .047'' (1
- 2mm) dia. wire 3.15'' (80mm) long
25 6666395
- 6666395 - SEAL RING
26 6666387
- 6666387 - PLUG
27 6665603
- 6665603 - FILTER
- OIL ENG 12
- engine
28 6666530
- 6666530 - CAP
- oil fill
29 6666722
- 6666722 - BUSHING
30 6666719
- 6666719 - BOLT
31 6668945
- 6668945 - THERMOSTAT
- engine oil temp. - rated @ 199.4 degrees F (93 degrees C)
32 6669067
- 6669067 - WASHER
33 6666703
- 6666703 - PLUG
34 6668941
- 6668941 - SPRING
35 6666716
- 6666716 - COVER
- soft
36 6672873
- 6672873 - PLUG
37 6672874
- 6672874 - PLUG
38 6666702
- 6666702 - PLUG
39 6666741
- 6666741 - VALVE
40 6688194
- 6688194 - STUD
- Was 6666709
41 6666746
- 6666746 - NOZZLE
- piston cooling
42 6672872
- 6672872 - PLUG
43 6666751
- 6666751 - PLUG
44 6666718
- 6666718 - SLEEVE
- guide
45 6666697
- 6666697 - COVER
- soft
46 6672878
- 6672878 - PLUG
47 6666738
- 6666738 - BUSHING
- wrapped bushing
48 6666737
- 6666737 - BUSHING
- wrapped bushing
49 6668946
- 6668946 - PLUG
- Was 6672877
50 6666395
- 6666395 - SEAL RING
51 6665910
- 6665910 - GASKET
52 6666407
- 6666407 - STUD
53 4DM8
- 4DM8 - NUT HEX
- Was 6666398
54 6666400
- 6666400 - PLUG
- Was 6666689
55 6666690
- 6666690 - PLUG
56 6666699
- 6666699 - O-RING
57 6632823
- 6632823 - GASKET
- LIQUID
- Liquid - Use between Ref. 17 & block also between Ref. 13 block
58 7028293
- 7028293 - RING
- SEALING
- Use W/Ref. 22 (NLA/ 6673173 turbocharger) - Was 6668108
59 6668107
- 6668107 - ADAPTER
- for 6673173 turbocharger
60 6668109
- 6668109 - SEAL
- O-RING
61 6666397
- 6666397 - PLUG
62 2FM22270
- 2FM22270 - WASHER
63 6714500
- 6714500 - TUBE
- oil drain
64 6518121
- 6518121 - PLUG
- oil drain
65 35C512
- 35C512 - SCREW FLGD HEX CAP
66 97D5
- 97D5 - NUT FLGD HEX LOCK
67 58K114
- 58K114 - O RING 10
68 6668905
- 6668905 - PIN
69 6668895
- 6668895 - KIT
- REPAIR
- turbocharger - includes snap ring
- O-ring
- & (3) bolts
70 6668903
- 6668903 - SPRING
- Red - .055'' (1
- 4mm) dia. wire 3.07 (78mm) long
71 6668902
- 6668902 - SPRING
- Blue - .039'' (1
- 0mm) dia. wire 2.44'' (62mm) long
72 6668900
- 6668900 - ADAPTER
- W/Ref. 82
73 6668901
- 6668901 - ADAPTER
- W/Ref. 82
74 6666400
- 6666400 - PLUG
- Was 6668889
75 6669066
- 6669066 - RING BRASS
76 6672879
- 6672879 - LINER
- CYL
- - cylinder
77 6666509
- 6666509 - RETAINER
- Was 6673155
78 6677576
- 6677576 - FLANGE
79 6677577
- 6677577 - GASKET
80 6677578
- 6677578 - BOLT
81 6684240
- 6684240 - OIL CAP
- Oil fill W/Ref. 84
82 6684241
- 6684241 - EXTENSION
- Use W/Ref. 86
83 6684242
- 6684242 - WASHER
