PLUG 6680019 (1)
1 6680019
- 6680019 - PLUG
- Model 5840-003-065
2 6674063
- 6674063 - PLUG
- Model 5840-003-063
3 6674709
- 6674709 - SHAFT
4 6674727
- 6674727 - SEAL
- OIL
5 6674725
- 6674725 - BEARING
6 6674056
- 6674056 - SEAL
- Was 6691212
7 6660018
- 6660018 - BEARING
- MOTOR DRIVE
8 6674062
- 6674062 - WASHER
- preload - .157" (4
- 0mm) thick
9 6660016
- 6660016 - RING
- SPLIT
10 6676597
- 6676597 - O-RING
- Was 6660044
11 6691215
- 6691215 - NUT
- Was 6674724
12 6674706
- 6674706 - STUD
13 6675234
- 6675234 - CAM RING
- Was 6674065
14 6676909
- 6676909 - DISTRIBUTOR
- for 5840-003-065
15 6660033
- 6660033 - SPRING
16 6660034
- 6660034 - SEAL
- W/ O-ring - Was 6674848
17 6674847
- 6674847 - SEAL
- W/ o-ring - for 5840-003-063 - Was 6660035
18 6676910
- 6676910 - SEAL
- W/ o-ring - for 5840-003-065
19 6674846
- 6674846 - SEAL KIT 3
- W/ o-ring - Was 6674730
20 6674345
- 6674345 - PLUG
21 6671784
- 6671784 - O-RING
- Was 6674851
22 6674344
- 6674344 - SPRING
23 6674343
- 6674343 - SHIM
- 0
- 6 mm
24 6674853
- 6674853 - POPPET
25 6674839
- 6674839 - PLUG
- W/Ref. 31
26 6674841
- 6674841 - SPRING
27 6675866
- 6675866 - SPOOL
- for model 5840-003-063 - Was 6674337
28 6675866
- 6675866 - SPOOL
- for 5840-003-065
29 6675867
- 6675867 - WASHER
30 6671749
- 6671749 - O-RING
31 6674852
- 6674852 - PLUG
- W/Ref. 35
32 6691217
- 6691217 - SCREW
- M16 x 70mm - The serial number listed is the vendor serial number - Was 6674704
33 6660032
- 6660032 - STOP PIN
34 6674850
- 6674850 - O-RING
- some machines may not have this o-ring
- it is not needed
35 6674066
- 6674066 - SEAL
36 6671758
- 6671758 - O-RING
37 6666364
- 6666364 - PLUG
- W/Ref. 41
38 6674017
- 6674017 - PLUG
- W/Ref. 43
39 6676908
- 6676908 - REAR HOUSNG
- for 5840-003-065
40 6678779
- 6678779 - HOUSING
- for 6677828 o-ring
41 6674718
- 6674718 - SHAFT
42 6674722
- 6674722 - SHIM
- .004" (0
- 1mm) thick
43 6674723
- 6674723 - SHIM
- .012" (0
- 3mm) thick
44 6674714
- 6674714 - BRAKE
- DISC
- outer brake
45 6674713
- 6674713 - BRAKE
- DISC
- inner brake
46 6674715
- 6674715 - SEAL
- green W/ step
47 6677828
- 6677828 - SEAL
- OIL
- green W/ metal washer
48 6674708
- 6674708 - WASHER
49 6691238
- 6691238 - BOLT
- Was 6689127
50 6674734
- 6674734 - BUSHING
51 6674712
- 6674712 - PISTON
- brake
52 6674728
- 6674728 - SEAL
- RING
- Was 6691237
53 6674726
- 6674726 - WASHER
54 6674720
- 6674720 - GASKET
- MOTOR HYD
55 6674716
- 6674716 - COVER
56 6674705
- 6674705 - O-RING
57 6674707
- 6674707 - PLUG
58 3GM820
- 3GM820 - SCREW
- Was 6674702
59 7024981
- 7024981 - OIL
- SYNTHETIC DRIVE MOTOR 4
- 236 ml (8 oz) - Was 6682546
60 6678777
- 6678777 - BRAKE ASSEMBLY
- Ref. 46-63
61 6674735
- 6674735 - BRAKE ASSEMBLY
- Ref. 46-63
