PLUG 6674063
1 6674063
- 6674063 - PLUG
- for models 5840-003-063 & 5840-003-065
2 6680019
- 6680019 - PLUG
- for models 5840-003-075 & 5840-003-079
3 6681620
- 6681620 - SHAFT
- MOTOR DRIVE
4 6674727
- 6674727 - SEAL
- OIL
5 6684933
- 6684933 - BEARING
- 70mm x 110mm x 25mm - for model 5840-003-079
6 6674725
- 6674725 - BEARING
- 70mm x 110mm x 19mm
7 6681621
- 6681621 - HOUSING
- for models 5840-003-075 & 5840-003-079
8 6674056
- 6674056 - SEAL
- Was 6691212
9 6660018
- 6660018 - BEARING
- MOTOR DRIVE
10 6660016
- 6660016 - RING
- SPLIT
11 6676597
- 6676597 - O-RING
- Was 6660044
12 6674724
- 6674724 - NUT
13 6674706
- 6674706 - STUD
14 6674065
- 6674065 - CAM ROTOR
- Was 6675234
15 6676909
- 6676909 - DISTRIBUTOR
- for models 5840-003-065
- 5840-003-075 & 5840-003-079
16 6660033
- 6660033 - SPRING
17 6660034
- 6660034 - SEAL
- W/ O-ring - Was 6674848
18 6674847
- 6674847 - SEAL
- W/ O-ring - for model 5840-003-063 - Was 6660035
19 6676910
- 6676910 - SEAL
- W/ O-ring - for models 5840-003-065
- 5840-003-075 & 5840-003-079
20 6660037
- 6660037 - SEAL
- W/ O-ring - Was 6674846
21 6674345
- 6674345 - PLUG
22 6671784
- 6671784 - O-RING
- Was 6674851
23 6675869
- 6675869 - O-RING
- for models 5840-003-075 & 5840-003-079
24 6674344
- 6674344 - SPRING
25 6674343
- 6674343 - SHIM
- 0
- 6 mm
26 6674853
- 6674853 - POPPET
27 6676952
- 6676952 - PLUG
- W/Ref. 31 - for models 5840-003-065 & 5840-003-075
28 6678115
- 6678115 - PLUG
- W/Ref. 31 - for model 5840-003-079
29 6674839
- 6674839 - PLUG
- W/Ref. 31 - for model 5840-003-063
30 6674841
- 6674841 - SPRING
31 6675866
- 6675866 - SPOOL
- for model 5840-003-063 - Was 6674337
32 6675866
- 6675866 - SPOOL
- for models 5840-003-065
- 5840-003-075 & 5840-003-079
33 6675867
- 6675867 - WASHER
34 6671749
- 6671749 - O-RING
- for model 5840-003-063
35 6685456
- 6685456 - O-RING
- for models 5840-003-075 & 5840-003-079
36 6676023
- 6676023 - O-RING
- 5840-003-065
37 6676952
- 6676952 - PLUG
- W/Ref. 35 - Was 6674852
38 6691217
- 6691217 - SCREW
- Was 6674704
39 6660032
- 6660032 - STOP PIN
40 6674850
- 6674850 - O-RING
- some machines may not have this o-ring
- it is not needed
41 6674066
- 6674066 - SEAL
42 6671758
- 6671758 - O-RING
43 6666364
- 6666364 - PLUG
- W/Ref. 41
44 6674017
- 6674017 - PLUG
- W/Ref. 43
45 6676908
- 6676908 - REAR HOUSNG
- for model 5840-003-065
46 6678779
- 6678779 - HOUSING
47 6674718
- 6674718 - SHAFT
- for models 5840-003-063 & 5840-003-065
48 6681622
- 6681622 - SHAFT BRAKE
- for models 5840-003-075 & 5840-003-079
49 6674722
- 6674722 - SHIM
- .004" (0
- 1mm) thick
50 6674723
- 6674723 - SHIM
- .012" (0
- 3mm) thick
51 6674714
- 6674714 - BRAKE
- DISC
- outer brake
52 6674714
- 6674714 - BRAKE
- DISC
- outer brake - for model 5840-003-079
53 6674713
- 6674713 - BRAKE
- DISC
- inner brake
54 6674713
- 6674713 - BRAKE
- DISC
- inner brake - for model 5840-003-079
55 6674715
- 6674715 - SEAL
- green W/ step
56 6677828
- 6677828 - SEAL
- OIL
- green W/ metal washer
57 6674708
- 6674708 - WASHER
58 6691238
- 6691238 - BOLT
- Was 6689127
59 6674734
- 6674734 - BUSHING
60 6674712
- 6674712 - PISTON
- brake - 30
- 05mm thick - See Insert
61 6681638
- 6681638 - PISTON
- brake - 28
- 15mm thick - See Insert - for model 5840-003-079
62 6674066
- 6674066 - SEAL
- for Model 5840-003-079
63 6674728
- 6674728 - SEAL
- RING
- Was 6691237
64 6678780
- 6678780 - WASHER
65 6674726
- 6674726 - WASHER
66 6674720
- 6674720 - GASKET
- MOTOR HYD
67 6674716
- 6674716 - COVER
68 6674705
- 6674705 - O-RING
69 6674707
- 6674707 - PLUG
70 3GM820
- 3GM820 - SCREW
- Was 6674702
71 7024981
- 7024981 - OIL
- SYNTHETIC DRIVE MOTOR 4
- 236 ml (8 oz) - Was 6682546
72 6674735
- 6674735 - BRAKE ASSEMBLY
- Ref. 46-63 - models 5840-003-063 & 5840-003-065
73 6678777
- 6678777 - BRAKE ASSEMBLY
- Ref. 46-63 - 5840-003-075
74 6681637
- 6681637 - BRAKE
- HYD MOTOR
- Ref. 46-63 - for model 5840-003-079
75 6678778
- 6678778 - KIT
- SEAL
- W/Ref. 7
- 11
- 22
- 23 (2) (6676910 )
- 24
- 26
- 30
- 34
- 35
- 39-41
- 52
- 57 & 59 - for model 5840-003-065
76 6678778
- 6678778 - KIT
- SEAL
- W/Ref. 4
- 7
- 11
- 22
- 23(6676910)
- 24
- 26
- 35(6685456)
- 40
- 52
- 57(6674728) & 59 - for models 5840-003-075 - & 5840-003-079
