FRAME 6511625

FRAME 6511625

FRAME 6511625

1 6511625

  • 6511625 - FRAME

2 6511627

  • 6511627 - HOLDER
  • brush

3 884581

  • 884581 - SWITCH
  • starter

4 896126

  • 896126 - LEVER

5 6656398

  • 6656398 - HOLDER
  • brush - insulated - Was 891252B

6 6511626

  • 6511626 - HOLDER
  • brush Grounded

7 6511628

  • 6511628 - COIL
  • 4 Coils

8 6511629

  • 6511629 - ARMATURE

9 6511630

  • 6511630 - DRIVE

10 6511631

  • 6511631 - HOUSING
  • drive - W/Ref. 34

11 860669

  • 860669 - BUSHING

12 61D6

  • 61D6 - NUT HEX FINISHED GR5

13 12D12

  • 12D12 - NUT

14 6551591

  • 6551591 - KIT
  • brush holder - Ref. 4
  • 20-22
